GEMÜ 1441
www.gemu-group.com
9 / 19
Resolution: 12 bit
Reverse battery protec-
tion:
Yes
Overload proof: Yes (up to 30 V DC)
Analogue output
Accuracy: ≤ ±1% of full flow
Signal: 4 - 20 mA
Supply voltage: 10 – 30 V DC
Output type: passive
Temperature drift: ≤ ±0.5% of full flow
Resolution: 0.1 %
Short-circuit proof: Yes
Overload proof: Yes (up to 30 V DC)
Digital input
Function: Can be selected using software
Input type: passive
Input voltage: Typically 24 V DC (10—30 V DC)
Logic level "1": 10 — 30 V DC
Logic level "0": 0–5 V DC
Input current: Typically 6 mA DC
Digital output
Note: Limit the current consumption to < 15 mA.
Function: selectable using software
Supply voltage: Typically 24 V DC (7–30 V DC)
Output type: passive
Logic level "1": conductive
Logic level "0": disabled
Travel sensor input (for travel length code S01 – remote potentiometer)
Note: Travel sensor input is not galvanically isolated from the supply voltage/set value input.
Input voltage
range:
0 to U
P+
Supply
voltage UP+:
Typically 0.48 V DC
Resistance range of re-
mote potentiometers:
1.8–6 kΩ (ideal 5 kΩ ±20%)
Technical data
