GEM Owner’s Manual - Page 52
Operation and Maintenance
Flooded Battery Fill Well
1. Bottom of Fill Well
2. Vent Cap
The detailed view in Figure 20 shows the internal features of a fill
well. Each battery contains two vent caps and six fill wells. In Figure
20, only one vent cap was removed to expose the fill wells.
*See Page 55 for filling instructions
Figure 20 - Fill Wells of Flooded Battery
2
Top of Battery
Battery Plates
1
