STANDARD 48V FUSES
APPLICATION SIZE LOCATION
Motor Controller/ BMC
5 amp
48V Fuse Center
DC-DC; Charger 30 amp 48V Fuse Center
OPTIONAL 48V FUSES
APPLICATION SIZE LOCATION
Lithium-ion 5 amp Lithium-ion Harness
Heater Heating Element 30 amp Heater Harness
Defrost 30 amp Defrost Harness
NOTICE
12V fuses must not be used in 48V applications. 48V fuses must not be used in
12V applications. Always install fuses with the recommended amperage to
avoid damage to the electrical system.
TIRES
WARNING
Operating your vehicle with worn tires, improperly inflated tires, non-standard
tires or improperly installed tires will affect vehicle handling and could cause an
accident resulting in serious injury or death. Always follow all tire maintenance
procedures as outlined in this manual and on the labels on the vehicle. Always
use original equipment size and type when replacing tires.
62
MAINTENANCE
