GEM e2 2018 - Specifications

SPECIFICATIONS
GEM E2 GEM E4
DIMENSIONS
Dry Weight 1200 lbs. (544 kg) 1350 lbs. (612 kg)
Length 103 in. (262 cm) 135 in. (343 cm)
Width
55.5 in. (141 cm) 55.5 in. (141 cm)
Height 73.1 in. (186 cm) 73.1 in. (186 cm)
Wheelbase
69 in. (175 cm) 101 in. (257 cm)
Turning Circle/Radius 150 in. (381 cm) 207 in. (526 cm)
LOAD CAPACITY
Payload Capacity
(occupants, cargo,
options)
800 lbs. (363 kg) 1150 lbs. (521.6 kg)
Gross Vehicle Weight
Rating (GVWR)
2000 lbs. (907 kg) 1150 lbs. (521.6 kg)
Gross Axle Weight
Rating (GAWR), Front
and Rear
1280 lbs. (581 kg) 1600 lbs. (726 kg)
Seating
2 4
PERFORMANCE
Motor
5 kW (optional 6.5 kW) AC electric
Motor peak 13.3 kW (optional 18.5 kW)
Controller Sevcon 450A AC Controller
Maximum speed 25 MPH (40 km/h)
Range
Varies with conditions
Drive System 17.05:1 Single speed
On-board charger
Standard 1 kW, 120/240V input (optional 3 kW or 6
kW, SAE J1772)
79
SPECIFICATIONS
