TRACTION BATTERY CONFIGURATIONS
NOTICE
Before accessing the batteries, make sure any wire or metal items remain
clear of the battery compartment to avoid causing a short circuit to the
electrical system.
Several battery pack configurations exist for GEM vehicles.
• Four 12-volt lead acid batteries
• Eight 6-volt lead acid batteries
• Single module lithium ion battery pack
• Dual module lithium ion battery pack
TRACTION BATTERY LOCATIONS
To access the battery pack, remove any rear accessory back installed on the
vehicle. See page 46. Release the battery pack access cover fasteners and
remove the cover.
ALL BATTERY CONFIGURATIONS
MODEL LOCATION
GEM e2 Under rear compartment
GEM e4 Under rear compartment
GEM e6® Under rear compartment
GEM eL XD Under rear bed compartment
71
MAINTENANCE
