Gema OptiFeed 4.0 PP07 User Manual

Rev. 00 12/21
76
•
Spare parts list OptiFeed 4.0 (PP07)
Pneumatic group
1
Throttle valve – complete
1016 590
2
Screw – M3x10 mm
216 739
3
Solenoid valve – 5/2 AP, 24 V DC
1020 404
4
Solenoid valve – 2x3/2 AP, 24 V DC
1020 403
5
Solenoid valve – 5/3 AP, 24 V DC
1020 405
6
Silencer – M5
1020 410
7
Elbow joint – 1/4"-Ø 10 mm
1000 219
8
Elbow joint – 1/8"-Ø 8 mm
251 372
9
Cartridge (vacuum suction nozzle)
1020 409
10
Plug – 1/4"
263 834
11
Screw-in nipple – 1/8"-Ø 6 mm
240 095
12
Elbow joint – 1/8"-Ø 4 mm
1005 258
13
Plastic tube – Ø 8/6 mm
103 756*
14
Elbow joint – 1/8"-Ø 8 mm
252 182
Hose connections
Connection
designation
Ø (mm)
Color
Order number
IN
10/8
black
103 250
6.4
8/6
black
103 756
A
8/6
blue
103 497
B
8/6
blue
103 497
F1
8/6
green
103 519
F2
8/6
green
103 519
1
6/4
green
1005 824
3
6/4
green
1005 824
PV
6/4
green
1005 824
2
6/4
blue
1005 825
4
6/4
blue
1005 825
TL
6/4
blue
1005 825
BP
6/4
black
103 144
Vacuum
4/2.7
black
104 469
* Please indicate length # Wearing part
