OptiSelect GM03 Assembly / Connection

19
Assembly / Connection
Connecting the gun
The gun is delivered ready-to-use by the manufacturer. Just a few cables
and hoses must be connected.
The compressed air must be free of oil and water!
The gun is connected as follows:
1. Connect electrode rinsing air hose and powder hose to gun
2. Lay out gun cable, electrode rinsing air hose and powder hose and
bind using Velcro strips (included)
3. Connect the gun cable plug to the socket 2.3 on the rear side of the
control unit
4. Connect electrode rinsing air hose to coupling 1.4
5. Connect powder hose to injector
