Getting Started with Cinterion
®
PLS62-W
2 Getting Started with PLS62-W
12
PLS62-W_startup_guide_v01 2018-05-17
Confidential / Released
Page 7 of 17
2 Getting Started with PLS62-W
2.1 Technical Requirements for Using PLS62-W Modules
• PLS62-W evaluation module
2
. For PLS62-W evaluation module schematics see Appendix:
Circuit Diagrams for Evaluation Module Board.
• PLS62-W USB driver package
• Computer running Windows 7 (or Windows 8), USB 2.0 High Speed compatible
• Local administrator privileges on the particular Windows computer to install and uninstall
the drivers
• DSB75 Development Support Board (for details see [3])
• DSB75 Adapter required for mounting the evaluation module to the DSB75. For more infor-
mation about the DSB75 Adapter please refer to Appendix: DSB75 Adapter.
• Accessories:
- Small 50 Ohms antenna adapter cables with SMT connectors to connect the U-FL con-
nectors on the PLS62-W evaluation module to the U.FL connectors on DSB75 Adapter
(e.g. a Hirose - Hirose cable such as delivered with each DSB75) - 1 for GSM/UMTS/LTE
main antenna connection, 1 for UMTS/LTE Rx Diversity antenna connection.
- External 50 Ohms RF antenna with SMA connector to connect the SMA connector on the
DSB75 Adapter (e.g. a SMARTEQ MiniMag antenna such as delivered with each
DSB75) - 1 for GSM/UMTS/LTE main antenna connection, 1 for UMTS/LTE Rx Diversity
antenna connection.
- 9 to 15 Volts power supply adapter applied at the DSB75 for powering up the DSB75 and
the connected PLS62-W evaluation module (not supplied by Gemalto M2M)
- RS-232 cables for the module's asynchronous serial interfaces ASC0 and ASC1 (not
supplied by Gemalto M2M)
- USB cable with mini-USB plug (not supplied by Gemalto M2M)
• Appropriate application for controlling the module from within a PC’s operating system. For
Windows, e.g. Windows Hyperterminal.
2.
For ordering information see [2].
