Gemini 7201 - Fitting Diagrams (7201); Main System Wiring; Connection Module 2344; Siren Connection (7147)

FITTING DIAGRAM
ref.7201
File:7201-UK CDR
YELLOW
+30
Ignition Key
GREEN-BROWN
Door Pin Switch
GREEN
Boot/Bonnet Pin Switches
BLACK marked M
Red
Black
YELLOW-GREY
RED-GREY
Refer to central door locking diagrams
Direction Indicator Lights
ORANGE
ORANGE
EARTH
YELLOW-BLACK
Supplementary Siren
with negative control
15A
BLACK marked R
Battery
12 VOLT
+
-
Aerial
Antena
Antenne
5A
5A
Push-Button 2
Push-Button 1
NOTE :
The Black wires have
the identification mark in the end.
Pink
Brown
Green/black
Ultrasonic module
YELLOW-RED
+ -
CLAMP
CLAMP
CLAMP
7059
5123
ON
21 3456
BATTERY
12 VOLT
+
_
BLACK
RED
7147
YELLOW-BLACK
Connection siren 7147 with alarm 7201.
2344
+30
2344
Connection module 2344 with 7201 alarm system.
White-Red
White-Brown
PINK
PINK
