EFFECTS
Panel
NO.4
1. FM ANTENNA : FM input socket
2. DC INPUT : DC input socket
3. MIC : Wired microphone input socket
4. GUITAR : Guitar input socket
5. LINE IN : Line input socket
6. CHARGING LIGHT
7. USB : USB input socket
8. POWER SWITCH : Switch power between ON or OFF.
9. LED DISPLAY : Display speaker status.
10. VOLUME/MULTI : Increase or decrease speaker main volume.
11. STANDBY
12. SOURCE : Press to change the source between BT, LINE, FM, USB
13. LIGHT MODE : Press to change the light mode between LED1,LED2,LED3,LED4,OFF
14. X DRIVE : on or off.Press to X DRIVE mode
15. PREV : Press this key to go to the previous track in USB/BT mode. In FM mode press to
tune to the previous channel.
16. PLAY/PAUSE/TWS : Press to play/pause a track. In FM mode press for the full automatic
search.Press to TWS (true wireless stereo) mode on or off.
17. In FM mode press to NEXT : Press this key to go to the next track in USB/BT mode.
tune to the next channel
18. EFFECTS: the menu MIC/GUITAR VOLUME, ECHO Press this key to change between
VOLUME,BASS, TREBLE.
Display" " mean for MIC/GUITER VOL 10, Rotate VOLUME/MULTI knob to adjust 0-30.
Display" " mean for ECHO VOL 10, Rotate VOLUME/MULTI knob to adjust 0-30.
Display" " mean for BASS 00, Rotate VOLUME/MULTI knob to adjust ± 6 dB.
Display" " mean for TREBLE 00, Rotate VOLUME/MULTI knob to adjust ± 6 dB.
