6
GLS Series
148.00 mm
105.00 mm
EFFECTS
Panel
1. FM ANTENNA :
Connect included antenna for FM radio
2. DC INPUT :
Connect included adapter to charge battery
3. MIC :
1/4” wired microphone input jack
4. GUITAR :
1/4” guitar input jack
5. LINE IN :
1/8” Aux input socket
6. CHARGING LIGHT
7. USB :
Play MP3 or WAV files from USB
8. POWER SWITCH :
Switch power between ON or OFF.
9. LED DISPLAY :
Display speaker status.
10. VOLUME/MULTI :
Increase or decrease speaker main
volume.
11. STANDBY: Suspend power
12. SOURCE :
Press to change the source between
BT, LINE, FM, USB
13. LIGHT MODE :
Press to change the light mode between LED1,LED2,LED3,LED4,OFF
14. X DRIVE :
X DRIVE mode increases bass for extra power, turn on or off.
15. PREV :
Press this key to go to the previous track in USB/BT mode. In FM mode press to tune to the
previous channel.
16. PLAY/PAUSE/TWS :
Press to play/pause a track. In FM mode press for the full automatic search.
Long press to turn TWS (true wireless stereo) mode on or off. See page 8.
17. NEXT :
Press this key to go to the next track in USB/BT mode.
In FM mode press to tune to the next channel
18. EFFECTS:
Press this key to change between the menu MIC/GUITAR VOLUME, ECHO VOLUME,BASS,
TREBLE.
Display" " mean for MIC/GUITER VOL 10, Rotate VOLUME/MULTI knob to adjust 0-30.
Display" " mean for ECHO VOL 10, Rotate VOLUME/MULTI knob to adjust 0-30.
Display" " mean for BASS 00, Rotate VOLUME/MULTI knob to adjust ± 6 dB.
Display" " mean for TREBLE 00, Rotate VOLUME/MULTI knob to adjust ± 6 dB.
