Dust Mites Power Remover
Carry out the maintenance if any waste threads or hair gets tangled in the remover.
Specication
Power Source : Re-chargeable battery
Power consumption for charging battery : Input: AC 200V - 240V ~ 50Hz/60Hz
Output: DC. 25V 200mA
Operating Voltage : 14.4V
Type of battery used : NiMH Battery
Required time for battery charging : 14 - 16 Hours
Usable temperature range for operation : 0˚C to 40˚C
Product dimension :
1) Stickvac : 280mm (L) x 200mm (W) x 1175mm (H)
(Not including charging base and dust mites removing power brush)
2) Handheld: 440mm (L) x 110mm (W) x 132mm (H)
3) Handheld with dust mites removing power brush : 490mm (L) x 112mm (W) x 132mm (H)
• Regular Maintenance
Maintenance when the power remover
cannot be manually rotated.
Slowly rotate the remover manually and remove
any foreign objects tangled around the brush.
1. Press the release button and
remove the cover.
3. Take out the rotating brush and
the remove the blockage.
2. Lift up the right side of the rotating
brush and then remove the belt
pulley from the belt.
4. Re-install the rotating brush again.
Finally, check if the brush cover is
securely xed and the rotating
brush rotates properly.
Take out the wastes
