Gemini UHF-01 Series - Page 21

GEGEVENS
DEUTSCHE
ONTVANGER
Frequency Range: 500-950MHz-
Frequency Stability: < 0.005%
Sensitivity: -100dBm
Mirror Image Rejection: >45 dB
Audio Output Level: 150mV(RMS)
S/N Ratio: >95dB
Distortion: <0.5%
Audio Output Level: <1V(10K)
Power Supply: DC12V 200MA
ZENDER
Frequency Range: 500-950MHz
Frequency Stability: 10ppm
RF Output: <10mW
Modulation: FM
Max Deviation: +75KHz
Power Supply: 3V (2 AA batteries)
Current Consumption: 100mA
UHF-01/02 manual • geminisound.com
21
