Portable Generator Owner’s Manual

This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

Obey all safety messages that follow this symbol to avoid possible injury or death.

Model No. 1314–0 (5500 Watt AC Generator) Manual No. B4360 Revision 4 (9/20/2000)

Visit our Generac website: www.generac-portables.com

5500XL

Questions and Answers

J
Jennifer PearsonAug 1, 2025
Why Generac Portable Products 5500XL Portable Generator engine will not start or runs rough?
- C
  Carol McmahonAug 1, 2025
  There are several reasons why your Generac Portable Products Portable Generator engine might not start or runs rough: * The Run/Stop switch may be set to "Stop". If so, set the switch to "Run". * The air cleaner might be dirty. Try cleaning or replacing it. * You might be out of gasoline, or the gasoline may be stale or contain water. Fill the fuel tank with fresh fuel. * The spark plug wire may not be connected, or the spark plug may be bad. Connect the wire or replace the spark plug. * The engine might be overchoking. Put the choke lever to "no choke" position. * The oil level could be low. Fill the crankcase to the proper level.
W
westmonicaAug 6, 2025
What to do if Generac Portable Products 5500XL engine is running, but no AC output is available?
- F
  Frank RivasAug 6, 2025
  If your Generac Portable Products Portable Generator engine is running but there's no AC output, consider these potential causes: * The circuit breaker might be open. Try resetting it. * There could be a poor connection or a defective cord set. Check and repair as needed. * The connected device might be faulty. Connect another device that is known to be in good condition.
R
Rebecca LewisAug 11, 2025
Why does my Generac Portable Products Portable Generator engine shut down during operation?
- N
  Noah CookAug 12, 2025
  Your Generac Portable Products Portable Generator engine might shut down during operation due to: * Being out of gasoline. Refill the fuel tank. * Having a low oil level. Add oil to the crankcase to reach the proper level.
M
mortizAug 16, 2025
What to do if Generac Portable Products Portable Generator engine runs good but bogs down when loads are connected?
- S
  Sherry HoffmanAug 16, 2025
  If your Generac Portable Products Portable Generator engine runs well but bogs down when loads are connected, it could be due to: * A short circuit in a connected load. Disconnect the shorted electrical load. * The generator being overloaded.
L
lvalenciaAug 21, 2025
Why Generac Portable Products 5500XL engine lacks power?
- A
  Angela JohnsonAug 21, 2025
  Your Generac Portable Products Portable Generator engine may lack power for a few reasons: * The load might be too high. * The air filter could be dirty. Replace it.
R
Richard MeyersAug 27, 2025
How to fix Generac Portable Products 5500XL engine that hunts or falters?
- A
  Adam RichardsonAug 27, 2025
  If your Generac Portable Products Portable Generator engine "hunts" or falters, it might be because the choke is opened too soon. Try moving the choke to the halfway position until the engine runs smoothly.

Summary

SAFETY RULES

EQUIPMENT DESCRIPTION

Overview of the generator's features, power output, and design.

GROUNDING THE GENERATOR

ASSEMBLY

INSTALL WHEEL KIT

Step-by-step guide for attaching the wheel kit to the generator for mobility.

OPERATION

BEFORE STARTING THE ENGINE

Instructions on adding oil and gasoline, and pre-operation checks.

OPERATING THE GENERATOR

Procedures for starting, connecting loads, and stopping the generator safely.

Charging a Battery

RECEPTACLES

120;240 Volt AC, 30 Amp Locking Receptacle

120 Volt AC, 30 Amp Locking Receptacle

DONT OVERLOAD THE GENERATOR

TROUBLESHOOTING

ELECTRICAL SCHEMATIC

WIRING DIAGRAM

EXPLODED VIEW - MAIN UNIT

PARTS LIST - MAIN UNIT

Generac Portable Products 5500XL Specifications

General

Fuel Type	Gasoline
Displacement	389 cc
Run Time at 50% Load	10 hours
Rated Watts	5500 W
Engine Type	OHV
Starting System	Recoil
AC Output	120/240V
Noise Level	72 dB
