Generac Power Systems 1.6L 18 kW User Manual

1 0G4827 1 ASSY RTR 104 KD1 HI EFF (18KW)
0G2927 1 RTR-102-20.0AD1 CPL (2006) (20KW)
0G2827 1 ASSY RTR 25KW 2P (2006) (25KW)
0G3451C 1 RTR 102 30KD2 (2006) CPL CHI (30KW)
2 0G0820A 1 HOUSING BLOWER LG PILOT
3 0G4452 1 BLOWER HOUSING SCREEN
4 020746 4 SCREW PPHM M5-0.8 X 8 ZINC
5 049226 4 WASHER LOCK M5
6 051713 4 WASHER FLAT M5
7 022129 4 WASHER LOCK M8-5/16
8 0G4825 1 ASSY STR 104-18AD1 HI EFF (18KW)
0G4826 1 ASSY STR 104 18GD1 HI EFF (18KW)
0G2926 1 STR-102-20.0AD1 CPL (2006) (20KW)
0G3682 1 STR-102-20.0GD1 CPL (2006) (20KW)
0G5584 1 STR-102-20.0JD1 CPL (2006) (20KW)
0G3685 1 STR-102-20.0KD1 CPL (2006) (20KW)
0G2826 1 ASSY STR 102 25AD1 (2006) (25KW)
0G3683 1 STR-102-25.0GD1 CPL (2006) (25KW)
0G6573 1 STR-102-25.0-JD1 CPL (2006) (25KW)
0G3686 1 STR-102-25.0KD1 CPL (2006) (25KW)
0G3452C 1 STR 102 30AD2 (2006) CPL CHI (30KW)
0G3684 1 STR-102-30.0GD2 CPL (30KW)
0G3687 1 STR-102-30.0KD2 CPL (30KW)
0G5909 1 ASSY STR 102 30AD2 10" (30KW)
0G6103 1 STR-102-30.0JD2
9 0A5382A 1 BEARING CARRIER REAR LG PILOT
10 075591 2 ASSY HOLDER BRUSH
11 051787 4 SCREW HHC M4-0.7 X 16 G8.8
12 0A5601A 1 COVER REAR BEARING
13 075554B 4 BOLT STATOR X 16" LG (20KW & 25KW)
075554E 4 SCREW HHC M8-1.25 X 463 G5 ZP (30KW)
14 0A9375 4 SCREW RHM #10-24 X 2
15 022152 4 WASHER LOCK #10
16 0G4196 1 FLYWHEEL & RINGGEAR ASSY 1.6L
17 042558 1 KEY SQ 3/8 X 1 STEEL
18 049814 4 SCREW HHC M10-1.5 X 25 G8.8
19 0G0965B 1 PLATE FLEX 1.6L R12.7
20 053607 1 SCREW HHC M12-1.75 X 35 G8.8
21 051769 1 WASHER LOCK M12
22 023365 4 WASHER SHAKEPROOF INT #8
(1) 23 0F3353 6 SCREW HHC M10-1.0 X 20 G10.9
24 072578 1 SPACER ROTOR SHAFT
25 0G3787 10 WASHER .41 ID .94 OD .12 THK
26 0A8830 4 WASHER FLAT .34 ID X .75 OD
27 077043E 1 FLEX CONDUIT 1" BLACK (NOT SHOWN)
28 0G2070 1 PLATE SPACER 14GA 1.6L
(1) APPLY LOCTITE 242 BEFORE THREADING SCREW INTO CRANKSHAFT.
