AASSSSEEMMBBLLYY
8
High Pressure Washer
Attach nozzle extension to spray gun by aligning
the locking tabs on the extension with the grooves
in the gun. Push extension inward and twist clock-
wise to lock in place (Figure 9).
Scew on the adjustable nozzle to the nozzle exten-
sion. Tighten until it locks.
CHECKLIST BEFORE
STARTING ENGINE
If you have reached this point, look back over the
assembly to see if you have performed all of the fol-
lowing.
Check for properly tightened hose connections
(high pressure and water supply) and for tight con-
nections and that there are no kinks, cuts, or
damage to the high pressure hose.
Check that oil has been added to proper level in
engine crankcase before trying to start the pressure
washer.
Add proper gasoline to fuel tank.
Provide proper water supply (not to exceed 140°F).
Be sure to read Safety Rules and Operation sec-
tions before using the pressure washer.
Figure 9 — Connect nozzle extension to spray
gun.
