Generac Portable Products 2,600PSI High Pressure Washer
5
IMPORTANT: Read entire owner’s manual before you
attempt to assemble or operate your new pressure washer.
REMOVE PRESSURE
WASHER FROM
CARTON
• Remove the parts box included with pressure washer.
• Slice two corners at the end of carton from top to
bottom so the panel can be folded down flat, then
remove all packing material.
• Roll pressure washer out of carton.
CARTON CONTENTS
Items in the carton include:
• Main Unit
• High Pressure Hose
• Parts Box (which includes the following):
• Carriage Bolts (2)
• Engine Manual
• Goggles
• Handle
• Knobs (2)
• Nozzle Cleaning Kit
• Nozzle Extension
• Owner’s Manual
• Owner’s Registration Card
• Oil Bottle
• O-Ring Maintenance Kit
• Spray Gun
• Wireform
If any of the above parts are missing or damaged, call the
pressure washer helpline at 1–800–270–1408.
PREPARING PRESSURE
WASHER FOR USE
If you have any problems with the assembly of your
pressure washer or if parts are missing or damaged, call the
pressure washer helpline at 1-800-270-1408.
To prepare your pressure washer for operation, you
will need to perform these tasks:
• Attach the handle and the wire form that holds the high
pressure hose and spray gun.
• Connect the high pressure hose to the spray gun and the
pump.
• Connect the water supply to the pump.
• Add oil to the engine crankcase.
• Add fuel to the fuel tank.
Attach Handle and Wire Form
NOTE: All assembly in this section will be as if assembling
from the rear of the pressure washer.
• Place the handle onto the handle supports already
connected to the main unit. Make sure the holes in the
handle align with the holes on the handle supports.
(Figure 1)
NOTE: It may be necessary to move the handle supports
from side to side in order to align the handle so it will slide
over the handle supports.
Make sure the
holes on the
handle are
aligned with the
holes on the
handle supports
Handle
Handle
Supports
Figure 1 — Attach the handle to the base.
