Generac Portable Products 2,600PSI High Pressure Washer
9
The adjustable nozzle permits you to adjust the spray
pressure and the spray pattern, as follows:
• Slide the nozzle forward to adjust the spray to low
pressure mode (Figure 10). Slide the nozzle backward to
achieve high pressure.
• Twisting the nozzle adjusts the spray pattern from a
narrow pattern to a fan pattern (Figure 10).
• Point the nozzle toward the ground and press the trigger
to test the pattern (Figure 11).
• Increase or decrease the pressure of the spray by turning
the pressure control knob counterclockwise or
clockwise respectively (Figure 12).
• For most effective cleaning, keep the spray nozzle
between 8 to 24 inches away from cleaning surface.
• If you get the spray nozzle too close, especially using high
pressure mode, you may damage the surface being
cleaned.
• Do Not get closer than 8 inches when cleaning tires.
Applying Detergent with the
Adjustable Nozzle
IMPORTANT: Use soaps designed specifically for
pressure washers. Household detergents could damage
the pump.
IMPORTANT: You must attach all hoses before you
start the engine. Starting the engine without all the hoses
connected and without the water turned ON will damage
the pump.
To apply detergent, follow these steps:
• Review the use of adjustable nozzles.
• Prepare the detergent solution as required by the job.
Figure 10 - Using the Adjustable Nozzle.
Slide nozzle backward
for high pressure mode.
Slide nozzle forward for
low pressure mode and
detergent application.
Twist nozzle
counterclockwise for fan
spray pattern.
Twist nozzle clockwise
for narrow spray
pattern.
Pressure
Control
Knob
Figure 11 — Test the Spray Pattern.
Figure 12 — Pressure control knob.
