ITEM PART # QTY. DESCRIPTION
81 67890 1 M20 Hex Nut
82 88433 1 Top Wrapper
83 45756 7 M6 X 10 Taptite
84 78609 2 Cover Bolts
85 73104B 1 Air Box Cover
86 92437 1 Blower Housing
87 88434 1 Lower Wrapper
88 66476 4 M6 X 12 HHCS
89 96195 1 Recoil Assembly
90 96196 1 Recoil Cup
91A 73116C 1 Backplate
91B 73116A 1 Backplate, E. SRT
92 81668 5 M6 X 10 HHCS
93 B2160 1 Rubber Spacer
— 21 —
GGeenneerraacc GGNN--332200//336600//441100 EEnnggiinnee
EEXXPPLLOODDEEDD VVIIEEWW —— SSTTEEPPPPEERR MMOOTTOORR,, FFLLYYWWHHEEEELL,, RREECCOOIILL SSTTAARRTTEERR
ITEM PART # QTY. DESCRIPTION
17 21544 1 Starter Motor Assm.
22 40976 2 SHCS M8 — 1.25 X 20
26 22129 2 Lock Washer M8
78 82774 1 Woodruff Key
79A SRV77147A 1 360 Flywheel
79B SRV91222B 1 320/360 Flywheel Ring Gear
79C SRV91222C 1 410 Flywheel Ring Gear
79D SRV21745G 1 410 Flywheel
80 67198N 1 Conical Washer
