Owner’s Manual for Portable Generator 5
Emissions
The United States Environmental Protection
Agency (US EPA) (and California Air
Resources Board (CARB), for engines/equip-
ment certified to California standards) requires
this engine/equipment to comply with exhaust
and evaporative emissions standards. Locate
the emissions compliance decal on the engine
to determine applicable standards. See the
included emissions warranty for emissions
warranty information. Follow the maintenance
specifications in this manual to ensure the
engine complies with applicable emissions
standards for the duration of the product’s life.
TABLE 2. Product Specifications
Generator Specifications 2500i
Rated Power 2200 W
Surge Power 2500 VA
Rated AC Voltage 120V
Rated AC Load at 120V 18.3 Amps**
Rated Frequency 60 Hz
Dimensions L x W x H (in/mm) 19.8 x 11.5 x 17.9 (504 x 293 x 454)
Weight (dry) 48 lb. (21.8 kg)
** Operating Temperature Range: -17.8 °C (0 °F) to 40 °C (104 °F). When operated above 25 °C (77
°F) there may be a decrease in power.
** Maximum wattage and current are subject to, and limited by, such factors as fuel Btu content,
ambient temperature, altitude, engine condition, etc.. Maximum power decreases about 3.5% for
each 1,000 feet above sea level; and will also decrease about 1% for each 6 °C (10 °F) above 16
°C (60 °F) ambient temperature.
Engine Specifications 2500i
Engine Type Single Cylinder, 4-stroke
Displacement 98 cc
Spark Plug Part Number 0K95530157
Spark Plug Type E6TC / E6RTC / BPR6HS or equivalent
Spark Plug Gap (in/mm) 0.024-0.028 (0.6-0.7)
Fuel Capacity / Type 3.8 L (1.0 U.S. gallons) / Unleaded
Oil Type
See
Add Engine Oil
Oil Capacity 0.35 L (0.36 qt.)
Run Time at 50% Load 4.0 Hours
* Go to www.generac.com or contact an IASD for replacement parts.
