ITEM PART NO. QTY. DESCRIPTION
1 0A7437 1 PANEL ANNUNCIATOR REAR
2 0A6388D 1 ASSY, 20LT MODBUS ANNUN G-PNL
4 040213 6 PCB SUPPORT SNAP-IN 1/4"
5 0A6990 1 SUPPORT, PC BOARD
6 036901 4 SCREW PPHM #6-32 X 3/8
7 0A7438 1 PANEL ANNUNCIATOR FRONT
8 0A6733 1 DECAL ANNUNCIATOR PANEL
10 061284 3 SWITCH ROCKER SPST 10@125V SPD
11 032300 1 HOLDER FUSE
12 044299 1 FUSE 1A X AGC1
13 061286 1 SOUNALERT, BUZZER
14 065511 1 PLUG PANEL PLASTIC 1/2"
16 036918 4 SCREW PPHM #8-32 X 1/2
17 025034 1 PLUG STEEL 1.0625
18 0E5620 1 HARNESS,10 WIRE REMOTE ANN
19 022985 4 WASHER FLAT #6 ZINC
20 022155 4 WASHER LOCK #6
21 022188 4 NUT HEX #6-32 STEEL
22 0F0172 1 DECAL MODEL NO. 04997-0
23 0D4462 1 DECAL,WIRING,REMOTE ANNUNCIATOR
VIEW A
-
A
VIEW B
-
B
[
OTHER SIDE OF PANEL
]
0
521
0
8
1
6
B
A
J
1
0
5
4
A
1
8
1
4
B
3
1
2
3
1
2
1
7
22
7
2
0
1
9
6
21
1
3
3
1
1
D
2
E
12
11
20-light Remote Annunciator
Assembly - Drawing No. 0F0173
