3.)
UL CIRCUIT BREAKER (225AF)
A 0F4173 1 COVER CB C5 225AF
C 0F4165$ REF CIRCUIT BREAKERS 200A FRAME
D 0F4186 1 COVER CB DISH 225AF
E 036261 4 RIVET POP .125 X .275 SS
F 053640 4 SCREW RHM #8-32 X 3-1/4
G 038150 4 WASHER FLAT #8 ZINC
H 022264 4 WASHER LOCK #8-M4
J 022471 4 NUT HEX #8-32 STEEL
K 029289 2 TAPE ELEC 1/2 FOAM
L 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
M 022129 9 WASHER LOCK M8-5/16
N 0F8432 1 INSULATOR CB 225AF
P 0C2454 7 SCREW THF M6-1 X 16 N WA Z/JS
R 0F8451 3 LUG SLDLSS 300 MCM-6 AL/CU
S 049897 6 SCREW SHC M8-1.25 X 20 G8
T 022145 6 WASHER FLAT 5/16-M8 ZINC
U 045771 3 NUT HEX M8-1.25 G8 CLEAR ZINC
V 0F8843 3 BUS BAR 200A LUG ADAPTOR
(1) W W/CB 2 TERMINAL COVER CB
X 0G3259 1 DECAL TERMINAL SHOCK HZD BI
Y 058306 3 SCREW SHC M8-1.25 X 25 G12.9
4.) UL CIRCUIT BREAKER (400AF)
A 0F4175 1 COVER CB C5 400AF
C 0F4166$ REF CIRCUIT BREAKERS 400A FRAME
D 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
E 042419 4 SCREW RHM 10-32 X 4
F 023897 4 WASHER FLAT #10 ZINC
G 022152 4 WASHER LOCK #10
H 022158 4 NUT HEX #10-32 STEEL
J 0C2454 7 SCREW THF M6-1 X 16 N WA Z/JS
K 029289 1 TAPE ELEC 1/2 FOAM
(2) L 052647 2/3 SCREW SHC M10-1.5 X 25 G12.9
(2) M 046526 2/3 WASHER LOCK M10
N W/CB 3 BUS BAR CB ADAPTER 225-400 A
P 0A7822 3 LUG SLDLSS 600/250-1/0 X 1/4-28
R 022131 3 WASHER FLAT 3/8-M10 ZINC
(1) S W/CB 2 TERM COVER CB
T 023334 6 SCREW HHC 1/4-28 X 1/2 G5
U 022097 6 WASHER LOCK M6-1/4
V 022473 6 WASHER FLAT 1/4-M6 ZINC
(2) W W/CB 2/3 SCREW SHC M10-1.5 X 25 G12.9
(2) X W/CB 2/3 WASHER LOCK M10
Y 0G3259 1 DECAL TERMINAL SHOCK HZD BI
5.) UL CIRCUIT BREAKER (800AF)
A 0F4176 1 COVER CB C5 800AF
C 0F4167$ REF CIRCUIT BREAKERS 800A FRAME
D 0F8433 2 INSULATOR CB 800AF
E 024196 4 SCREW RHM 1/4-20 X 3-1/2
F 022473 4 WASHER FLAT 1/4-M6 ZINC
G 022097 4 WASHER LOCK M6-1/4
H 022127 4 NUT HEX 1/4-20 STEEL
J 0C2454 7 SCREW THF M6-1X16 N WA Z/JS
K 029289 2 TAPE ELEC 1/2 FOAM
L 060619 2/3 SCREW SHC M10-1.50 X 40 G12.9
M 022131 2/3 WASHER FLAT 3/8-M10 ZINC
N 022237 2/3 WASHER LOCK 3/8
P 045772 2/3 NUT HEX M10-1.5 G8 YEL CHR
R 0F9721 2/3 LUG SLDLSS 3/0-400X3 MCM AL/CU
S 0D2157 4/6 SCREW SHC M6-1.0 X 50 G8.8
T 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
(1) U W/CB 2 TERM COVER VITZROTECH 400AF CB
V 0G3259 1 DECAL TERMINAL SHOCK HZD BI
W 022097 4/6 WASHER LOCK M6-1/4
6.) NEUTRAL BLOCK 390 / 200-400A
A 0D5466 2 BUS BAR NEUTRAL BLOCK 390
B 039287 1 SCREW HHC M8-1.25 X 45 G8.8 FT
C 022145 1 WASHER FLAT 5/16-M8 ZINC
D 022129 1 WASHER LOCK M8-5/16
E 045771 1 NUT HEX M8-1.25 G8 YEL CHR
F 045335 2 SCREW HHC 1/4-28 X 3/4 G5
G 022097 2 WASHER LOCK M6-1/4
H 0A7822 1 LUG SLDLSS 600/250-1/0X1/4-28
(1) HARDWARE FOR MTG. CB TERMINAL COVERS IS SUPPLIED
WITH CIRCUIT BREAKERS.
(2) 2/3 QTY. 2POLE & 3 POLE CB.
