1
0F2885
1
PANEL CB CONN BOX
2 0G0171 1 STAND RH CONTROL CPL C5
0G0171A 1 STAND RH CONTROL CPL C5 2 HOLE
3 0G0172 1 STAND LH CONTROL CPL C5
4 023484N 1 BUSHING SNAP SB-2.5-31
5 0F4677 1 ASSY PCB INTERFACE 1PH 240V
067617030A - INTERFACE 3PHS 416/480V
067617030B - INTERFACE 3PHS 208/240V
6 043180 4 WASHER FLAT M4
7 022264 4 WASHER LOCK #8-M4
8 0C3990 4 SCREW PHTT M4-0.7 X 10 ZYC
9 * 057701 REF. BLOCK TERM 20A 8 X 6 X 1100V
10 022155 2 WASHER LOCK #6
11 0C2428 2 SCREW PHTT #6-32 X 1/2 ZYC
12 0F3618 1 DECAL CPL CUST CONN H CTRL
13 0A9457 1 DECAL NEUTRAL
14 057073 2 JUNCTION BLOCK 3/8-16
15 ** 0D5466 REF. BUS BAR NEUTRAL BLOCK 390
16 ** 0A7822 REF. LUG SLDLSS 600/250-1/0 X 1/4-28
17 022237 4 WASHER LOCK 3/8
18 022241 4 NUT HEX 3/8-16 STEEL
19 049226 6 WASHER LOCK M5
20 0C2266 6 SCREW PHTT M5-0.8 X 16 ZYC
21 0C2454 10 SCREW THF M6-1 X 16 N WA Z/JS
22 042568 4 SCREW HHC M6-1.0 X 20 G8.8
23 022473 12 WASHER FLAT 1/4-M6 ZINC
24 022097 8 WASHER LOCK M6-1/4
25 049813 4 NUT HEX M6 X 1.0 G8 YEL CHR
26 * 0D4698 1 BLOCK TERM 20A 6 X 3 X 1100V
27 0F4464 1 DECAL CUST CONN 120V UTILITY
28 025433 1 LUG SLDLSS #6-14 X 13/64 CU
29 024469 1 SCREW HHTT #10-32 X 3/8 CZ
30 067210A 1 DECAL GROUND LUG
31 0D6029 4 SCREW HHTT M6-1.0 X 16 ZYC
32 051713 2 WASHER FLAT M5
33 081008 1 GROMMET 1.25 X .25 X .75
34 077043J 3 CONDUIT FLEX 2.0" ID
35 0F6156 1 PLATE WIRE SNGL GALV
36
029289
1
TAPE ELEC 1/2 FOAM (AS REQ’D)
37*** 0F3113 REF ASSY PCB HSB CTRL IGN MODULE
38 047411 4 SCREW HHC M6-1.0 X 16 G8.8
39 036943 2 SCREW PPHM #10/32 X 2
40 023897 2 WASHER FLAT #10 ZINC
41 022152 2 WASHER LOCK #10
42 022158 2 NUT HEX #10-32 STEEL
1.) UL CIRCUIT BREAKER (800AF)
A 0G0173 1 COVER, CB 803 C5
C 0F4167$ REF CIRCUIT BREAKERS 800A FRAME
D 0F8433 2 INSUL CB 800AF
E 022477 4 SCREW RHM 1/4-20 X 1-1/2
F 022473 4 WASHER FLAT 1/4-M6 ZINC
G 022097 4 WASHER LOCK M6-1/4
H 022127 4 NUT HEX 1/4-20 STEEL
J 0F1733 1 DECAL CUSTOMER CONNECT INSIDE
K 029289 2 TAPE ELEC 1/2 FOAM
L 060619 2/3 SCREW SHC M10-1.50 X 40 G12.9
M 022131 2/3 WASHER FLAT 3/8-M10 ZINC
N 022237 2/3 WASHER LOCK 3/8
P 045772 2/3 NUT HEX M10-1.5 G8 YEL CHR
R 0F9721 2/3 LUG SLDLSS 3/0-400X3 MCM AL/CU
S 0D2157 4/6 SCREW SHC M6-1.0 X 50 G8.8
T**** W/CB 2 TERM. COVER VITZROTECH 400AF CB
U 0G3259 1 DECAL TERMINAL SHOCK HZD BI
V 022097 4/6 WASHER LOCK M6-1/4
2.) NEUTRAL BLOCK 390 / 200-400A
A 0D5466 1 BUS BAR NEUTRAL BLOCK 390
B 039287 1 SCREW HHC M8-1.25 X 45 G8.8 FT
C 022145 1 WASHER FLAT 5/16-M8 ZINC
D 022129 1 WASHER LOCK M8-5/16
E 045771 1 NUT HEX M8-1.25 G8 YEL CHR
F 045335 2 SCREW HHC 1/4-28 X 3/4 G5
G 083896 2 WASHER LOCK 1/4-M6 SS
H 0A7822 1 LUG SLDLSS 600/250-1/0 X 1/4-28
* ITEM INCLUDED WITH HARNESS
** ITEM INCLUDED WITH 0D5464B
*** ITEM IS PART OF 9R.
**** HARDWARE FOR MTG. CB TERMINAL COVERS IS
SUPPLIED WITH CIRCUIT BREAKERS.
