2 0F2122 1 GEAR CASE ALT. MACHINED
3 095613 1 SEAL OIL
4 051756 2 SCREW HHC M10-1.5 X 20 G8.8
5 046526 44 WASHER LOCK M10
6 049814 4 SCREW HHC M10-1.5 X 25 G8.8
7 051735 8 SCREW HHC M10-1.5 X 70 G8.8
8 0F2097 1 GASKET 390 GEARBOX
9 072879 1 SPACER .69 X 2.75 X .37 ST/ZNC
10 097557B 1 KEY 10 X 16 X 46
11 0H3114 1 GEAR OUTPUT 1.65:1
095970 1 GEAR OUT 390-50H 37T
095968 1 GEAR OUT 390-60H 35T
0E6866 1 GEAR OUTPUT 2:1 50HZ 390
12 070263 2 SCREW HHC M16-2.0 X 35 G10.9
13 057019 2 BALL BRG 65 X 120 X 23
14 026847 1 BREATHER
15 0H3113 1 GEAR INPUT 1.65: 1
095969 1 GEAR INPT 390-50 25T
095967 1 GEAR INPT 390-60 27T
0E6865 1 GEAR INPUT 2:1 50HZ 390
16 095966 1 SHAFT 390 INPUT GEAR
17 095976 1 COLLAR HARDENED
18 095971 1 SEAL OIL
19 096777 1 SNAP RING INT 120MM
20 057019S 1 BEARING #6213 SEALED
22 096379 1 PLATE INTRNL BRG RET
23 048189 2 PIN DOWEL M8 X 24
24 095979 1 PLATE BEARING THRST
25 021159 1 SPACER STRESSPROOF
26 097557A 1 KEY 10 X 16 X 40
27 057163 1 PLUG PIPE 3/8" MAGNETIC
28 0F6518 4 SCREW HHFC M10-1.5 X 25 G10.9
29 0F3201 1 COVER GEARBOX GUARD
30 020443 1 COUPLING INNER DRAWN
31 094666A 1 COUPLING OUTER MACHN
32 099828 8 DAMPER GB CPLR VIBRA
33 099828A 8 DAMPER GB CPLR VIBRA
34 026925 2 PLUG STD PIPE 3/8 STEEL SQ HD
35 097557C 1 KEY 10 X 16 X 50
36 038591 1 NIPPLE PIPE 3/8 NPT X 3-1/2
37 025066 1 COUPLING FULL 3/8-18
38 031578 6 SCREW HHC 3/8-16 X 1-1/2 G8
052625 REF. SCREW SHC M10-1.5 X 35 G12.9 (FORD ENGINES)
39 049814 10 SCREW HHC M10-1.5 X 25 G8.8
40 0A1786 2.5cc RETAINING COMPOUND
41 027175 .200 GAL LUBE GREASE SAE #90 80W90 (NOT SHOWN)
44 045772 10 NUT HEX M10-1.5 G8 YEL CHR
45 052243 10 SCREW HHC M10-1.5 X 60 G8.8
46 057642 2 SCREW HHC M10-1.5 X 40 G10.9
47 0F6487 4 WASHER FLAT M10 SEALING COPPER
48 0F6355 1 GASKET SEAL PLATE 390 GB
49 0F6477 .050 GAL ENHANCER GEAR OIL (NOT SHOWN)
50 0F6557 0.4cc THREADLOCK AND SEALANT
51 026924 1 ELBOW 90D STREET 3/8
