1 0F3017 1 BRACKET,D.C. ALTERNATOR LOWER
2 039253 3 SCREW HHC M8-1.25 X 20 G8.8
3 022129 4 WASHER LOCK M8-5/16
4 022145 4 WASHER FLAT 5/16-M8 ZINC
(2) 5 0D5419 REF OIL FILTER, FORD V-10 ENGINE
6 0D7055 1 DIPSTICK TUBE, FORD 6.8L
7 0D3488G 1 BELT SERPENTINE (65.0" LG) (1800 RPM)
0D3488J 1 BELT SERPENTINE (65.3" LG) (2300 RPM)
0D3488 1 BELT SERPENTINE (67.16" LG) (3000 RPM)
0D3488K 1 SERPENTINE BELT (68.3" LG) (3600 RPM)
8 057795A 1 BARBED EL 90 3/4 PLASTIC
9 059057 1 HOSE 3/4 ID SAE-30R2 (16.75”LG)
10 0F3287 1 BRACKET DC ALTERNATOR UPPER
(3) 11 0F5990 1 HARN ENG 6.8L H-100 (USE WITH PROBE P/N 0E2507)
0H2595 1 HARN ENG G6.8L G3 H-100 (USE WITH PROBE P/N 0H1827)
0F4419 1 HARN ENG 6.8L G-100 (USE WITH PROBE P/N 0E2507)
0H3081 1 HARN ENG G6.8L G3 MQT 480V (USE WITH PROBE P/N 0H1827)
0F9786 1 HARN ENG 6.8L G-100 MQT 208V (USE WITH PROBE P/N 0E2507)
0H3080 1 HARN ENG G6.8L G3 MQT 208V (USE WITH PROBE P/N 0H1827)
12 0E9868A 1 ALTERNATOR DC W/OUT PULLEY
13 057796 1 GROMMET
14 0F3216 1 PULLEY 80 OD DC ALTERNATOR (1800 RPM)
0F3216A 1 PULLEY 102 OD DC ALTERNATOR (2300 RPM)
0F3216C 1 PULLEY 132 OD DC ALTERNATOR (3000 RPM)
0F3216D 1 PULLEY 160 OD DC ALTERNATOR (3600 RPM)
15 035579 1 BSHG RDCR HEX 1/4 TO 1/8
16 0F4612 1 SENDER OIL PRESSURE 1/8" NPT
17 0D6658 1 DIPSTICK 6.8L FORD
(3) (1) 18 029333A 2 TIE WRAP UL 7.4" X .19" BLK
19 022097 3 WASHER LOCK M6-1/4
20 022473 3 WASHER FLAT 1/4 ZINC
21 042568 3 SCREW HHC M6-1.0 X 20 G8.8
22 0D8027 4 BOLT WATER PUMP PULLEY
23 0D8025 1 BOLT GROOVED IDLER PULLEY
24 0D8026 3 BOLT BELT TENSIONER
25 0D8030 1 TENSIONER ENG. AUTOMATIC BELT
26 0F2846 1 PULLEY WATER PUMP FORD (1800RPM UNITS)
0D8029 1 PULLEY ENGINE WATER PUMP (2-POLE & GEAR BOX)
27 0D8028 1 PULLEY GROOVED ENGINE IDLER
28 045771 1 NUT HEX M8-1.25 G8 YEL CHR
29 0D3454A 1 ENGINE G6.8L G3 V-10
0H0923 1 ENGINE G6.8L G3 V-10 (2009)
30 022131 2 WASHER FLAT 3/8-M10 ZINC
31 046526 1 WASHER LOCK M10
32 064416 1 SCREW HHC M10-1.5 X 45 G8.8 FT
33 045772 1 NUT HEX M10-1.5 G8 YEL CHR
34 0F3217 1 SPACER DC ALTERNATOR PULLEY
35 0F2776A 1 BRACKET SIGNAL CONDITIONER
36 0F6151 1 CAP RUBBER
37 0F4308 1 BRACKET DC ALT STABILIZER
38 0F3158 1 OIL COOLER FORD (150KW 3600RPM)
39 057823 2 CLAMP HOSE #10 .56-1.06
40 0E0502 1 TEMPERATURE SENDER DELPHI
41 0G0866 1 HOSE OIL COOLER PREFORMED 3/4 (150KW 3600RPM)
42 0F4301 1 HOSE OIL COOLER (150KW 3600RPM)
44 047527 1 BARBED STR 1/2NPT X 3/4
45 057823 4 CLAMP HOSE #10 .56-1.06 (150KW 3600RPM)
46 0E0992A 10 PLUG EXPANSION 14 OD
47 078637 A/R ADHESIVE LOCTITE 620
48 0G7519 1 DECAL EMISSION CTRL INFO 6.8L
49 0E8286 1 ELBOW 45D STREET 1/2NPT BRASS
(1) NOTE: I/N 18 IS FOR HOLDING SENSOR TO I/N 35.
(2) I/N 5 PART OF I/N 29.
(3) NOTE: NOT SHOWN)
