1
0J01150ST03
1
WELDMENT RADIATOR SUPPORT C5
2 0F2611 1 RADIATOR 680 X 680 X 70 CPL
3 0F5254 1 V-BELT 31/64" X 62-3/8"
0F7077 1 V-BELT 1/2" X 63-3/8" (6.8L, 100KW & 130KW)
4 046526 12 WASHER LOCK M10
(2) 5 059981 4 SCREW HHC M10-1.5 X 30 C10.9
6 0C2454 2 SCREW THF M6-1 X 16 N WA Z/JS
7 052250 2 TAPE FOAM 1 X 1 (26.75” LG)
8 076749 1 TANK COOLANT RECOVERY
9 0F2573 1 PULLEY FAN V-GROOVE 9"
10 0F2610 1 FAN 26" LH ROTATION
11
0H20620ST03
1
ARM BE
LT TENSIONER
(2) 12 0H2051 1 SHOULDER BOLT 1/2 X 2-1/4"
13 0F2862 1 SPRING TENSION CPL
14 0F2560 1 PULLEY V-BELT 4" FLANGED
15 022131 15 WASHER FLAT 3/8-M10 ZINC
(2) 16 039287 1 SCREW HHC M8-1.25 X 45 C8.8
17 0C8566 8 SCREW HHFC M6-1.0 X 20 G8.8
18 0F2561 1 HUB FLEX PLATE
19 0C8165 4 NUT HEX LOCK 5/16-24 NY INS
(2) 20 0D6795 1 SCREW HHC M12-1.5 X 60 G8.8
21 0C7043 12 DISK FLEX
22 0E8909 1 COUPLING HUB FLEX (MACH)
0E8909A 1 COUPLING HUB FLEX (MACHINING)
23 048031C 1 CLAMP HOSE BAND 1/4
(2) 24 0C8146 4 SCREW HHC 5/16-24 X 1.124
25 082774 2 KEY WOODRUFF 4 X 19D
26 0F2686 1 HOSE RADIATOR UPPER CPL
27 0F5463 1 HOSE LOWER RAD CPL C5 6.8L
28 0F8695 1 ASSY BRG/SHAFT CPL FANDRIVE
29 0F4028 1 PULLEY 6.5" DIA MACHINED (6.8L 100KW)
0F4030 1 PULLEY 6" DIA MACHINED (6.8L 130KW)
0F4032 1 PULLEY 5.5" DIA MACHINED (5.4L 80KW & 6.8L 150KW)
(2) 30 042911 1 SCREW HHC M10-1.5 X 30 G8.8
31 0F2872 1 SCREW HHC 1/2-13 X 2" G8
32 022304 1 WASHER FLAT 1/2 ZINC
33 022195 1 WASHER LOCK 1/2
34 022196 1 NUT HEX 1/2-13 STEEL
35 049813 8 NUT HEX M6 X 1.0 G8 YEL CHR
36 052677 1 WASHER NYLON .50 X .87 X .06
37 090283 1 CAP RADIATOR 13 PSI
38 0F2776A 1 BRACKET, SIGNAL CONDITIONER
39 022145 4 WASHER FLAT 5/16-M8 ZINC
40 022129 2 WASHER LOCK M8-5/16
41 052644 1 SPACER .5 X 1.5 X .25 STL/ZINC
42 035685 4 CLAMP HOSE #28 1.32-2.25
43 045764 1 SCREW HHTT M4-0.7 X 8 BP
44 065852 1 SPRING CLIP HOLDER .37-.62
45 0C7649 1 CLAMP HOSE .38-.87
46 055596 1 BARBED STR 3/8 NPT X 3/8
47 069860E 1 HOSE DRAIN ASSY 28"
(1) 48 069811 REF CAP HEX 1/4 NPT BRASS
49 080713 1 BRACKET COOLANT TANK
50 022473 24 WASHER FLAT 1/4-M6 ZINC
51 022097 16 WASHER LOCK M6-1/4
52 042568 8 SCREW HHC M6-1.0 X 20 G8.8
53 0F5050B 1 SHIELD RADIATOR
54 039253 3 SCREW HHC M8-1.25 X 20 G8.8
55 051769 1 WASHER LOCK M12
56 0C8145 8 WASHER FLEX (THIN)
57 0H1827 1 PROBE COOLANT LEVEL 3/8-18NPTF
58 0H23980ST03 1 BRACKET TENSIONER SPRING
59 029032 1 HOSE 9/32 ID (43”LG)
60 049820 2 NUT HEX LOCK M8-1.25 NY INS
(3) 61 0H2844 2 (REF) BEARING SLEEVE 1/2/ X 3/4 X 1
62 0G53150AL0R 1 SPACER CPL COOLING FAN 1/8"
(4) 63 051756 4 / 5 SCREW HHC M10-1.5 X 20 C8.8
64 052625 3 SCREW SHC M10-1.5 X 35 G12.9
(4) 65 055934H 1 / 2 CLAMP STL/VNL .62 X .406 Z
66 072252 1 GROMMET 1.37 X .06 X 1.00
67 0D6029 1 SCREW HHTT M6-1.0 X 16 ZYC
68 0D3700 8 NUT FLANGE M6-1.0 NYLOK
(1) ITEM 48 IS INCLUDED WITH 47.
(2) APPLY MEDIUM STRENGTH BLUE THREAD LOCKING FLUID TO THREADS.
(3) ITEM 61 IS INCLUDED WITH ITEM 1.
(4) QTY REQ. FOR OPEN SETS. / QTY REQ. FOR ENCLOSED SETS.
