Generac Power Systems QT 100 User Manual

1 033212 4 SCREW HHC 5/16-18 X 1-1/4 G5
2 065908 1 SUPPORT NAT GAS SOLENOID
3 0G9240A 1 REG ASSY 5.4L 80KW NG CPL
0G9190B 1 REG ASSY 6.8L 100KW NG CPL
4 052617 2 SCREW HHC M12-1.75 X 20 G8.8
5 022304 2 WASHER FLAT 1/2 ZINC
6 022129 4 WASHER LOCK M8-5/16
7 045773 2 NUT HEX M12-1.75 G8 YEL CHR
8 022195 2 WASHER LOCK 1/2
9 039130 1 NIPPLE CLOSE 1.25 NPT X 1.625
10 030131 1 ELBOW 90D 1-1/4 NPT
11 031015 1 NIPPLE PIPE 1-1/4 NPT X 3 (100KW)
12 0F6279 1 HARNESS, FUEL JUMPER DUAL REG (100KW)
0G5989 1 HARNESS FUEL JUMPER DUAL REG
13 057822 8 CLAMP HOSE #8 .53-1.00
14 059057 1 HOSE 3/4 ID SAE-30R2 (42” LG)
15 0F4408 1 Y CONNECTOR 500 SERIES BARBS
16 0D1509 1 DECAL INLET PRESSURE
17 050279 1 DECAL FUEL INLET NG
18 0H2353 1 ASSY,ADAPTER,THROTTLE BODY
0F2756A 1 MACHINING, INTAKE ADAPTOR 60MM
19 0E4390 1 GASKET GOVERNOR ACTUATOR
20 0E4392 1 ACTUATOR BOSCH 60 GOVERNOR
21 0F0960 1 REDUCER 3.0" TO 2.75" TURBO
22 0F3885 1 MIXER 40/60MM ACTUATOR ASSY
23 0G3167 2 O-RING 2-3/4 X 3/32 X 2-15/16
24 0F3691E 1 VENTURI, THROTTLE 42MM (100KW)
0F3691C 1 VENTURI, THROTTLE 38MM
25 026915 2 NIPPLE CLOSE 3/4 X 1.375
26 0A8064 2 BSHG RDCR HEX 1-1/4-3/4
27 026073A 1 PLUG STD PIPE 1/4 STEEL SQ HD
28 0D2157 4 SCREW SHC M6-1.0 X 50 C8.8
29 039294 1 CLAMP HOSE #44 2.31-3.25
30 022097 4 WASHER LOCK M6-1/4
(1)31 049811 2 WASHER FLAT M6
(1)32 0D2698 1 GASKET ADAPTER THROT BODY
(1)33 042568 2 SCREW HHC M6-1.0 X 20 G8.8
34 064346 1 PIPE TEE 1-1/4 NPT
35 059057 1 HOSE 3/4 ID SAE-30R2 (45” LG)
36 066212 1 CLAMP HOSE #52 2.81-3.75
(1)37 0G46350ST03 1 BRACKET, HOSE RISER
38 059057 1 HOSE 3/4 ID SAE-30R2 (9.5” LG)
39 059057 1 HOSE 3/4 ID SAE-30R2 (12” LG)
(1)40 022097 2 WASHER LOCK M6-1/4
(1) G6.8L UNITS ONLY
