(2) 1 0F58730ST01 1 REAR WRAP C5
(2) 2 0F58680ST01 4 DOOR C5
(2) 3 0F58720ST01 2 CENTER SUPPORT C5
(3) 4 0F58710AL01 2 DISCHARGE DUCT LH & RH SIDE C5
(2) 5 0F58690ST01 2 FRONT CORNERS C5
(2) 6 0F58700ST01 1 DISCHARGE CENTER DUCT C5
(3) 7 0F58670AL01 1 ROOF C5 ALUM
11 0C2454 86 SCREW THF M6-1 X 16 N WA Z/JS
12 0F2766 2 SPLITTER
13 0F3181 4 SPLITTER SHORT
14 0F3185 2 STRINGER SPLITTER C3
15 0F3416 2 SUPPORT SPLITTER C5 130KW
16 0F3949 2 INSULATION CORNER POST
17 0C2634A 1 ASSEMBLY COVER ACCESS
18 022473 5 WASHER FLAT 1/4-M6 ZINC
19 022097 1 WASHER LOCK M6-1/4
20 022127 1 NUT HEX 1/4-20 STEEL
21 0F3072 20 INSULATION RETAINMENT HANGER
22 078115 58 WASHER SELF LOCKING DOME #4-40
23 0F3949B 3 INSULATION SPLITTER
24 0F3949A 4 INSULATION SHORT LOUVER
25 0F5048D 4 VISE-ACTION LATCH SLOTTED CIR
26 0E5968 1 GASKET EXTRUDED TRIM (566” LG)
27 0F5049 4 TAB PULL
28 0F3949L 2 INSULATION SPLITTER SML
29 0F3949E 1 INSULATION ROOF TOP REAR
30 0F3890A 9 RETAINER INSULATION (740)
31 087233 2 RIVET POP .1875 X .450 SS
32 0F3949C 1 INSULATION ROOF TOP
33 0F3949D 4 INSULATION DOOR
34 0F3949G 1 INSULATION DISCHARGE DUCT
35 0F3949J 2 INSULATION CENTER SUPPORT
36 0F3949K 1 INSULATION DISCHARGE DUCT TOP
37 0F3949F 2 INSULATION INNER DUCT SIDE
38 0F3890B 4 RETAINER INSULATION (820)
39 0F3890 14 RETAINER INSULATION (450)
40 042568 4 SCREW HHC M6-1.0 X 20 G8.8
42 022447 4 WASHER SHAKEPROOF INT 1/4
43 049813 4 NUT HEX M6 X 1.0 G8 YEL CHR
(1) 44 077992 28 NUT HEX LOCK M6-1.0 SS NY INS
45 0912970094 4 ASSY WIRE 14 AWG 34.8" GRN/YEL
46 0F2766A 1 SPLITTER C5
47 0F3949M 1 INSULATION SPLITTER SHRT MPS
48 0F8869D 1 KEY VISE-ACTION LATCH SLOT CIR
49 0E3257 6 SCREW TH-FRM M6 W/CAP SHKPRF W
50 078115A 12 WASHER SELF LOCKING DOME #8-32
51 066760 1 STRIP SEALANT 1/8 X 1 (44.52”LG)
(1) ALUMINUM ENCLOSURE NOTE: ALL ENCLOSURE PANELS THAT FASTEN TO
THE BASE FRAME MUST BE SECURED USING ITEM 11 & 49 THREAD FORMING
FASTENER AND ITEM 44 LOCK NUT. LOCK NUT IS TO BE INSTALLED AFTER THREAD
FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN ENCLOSURE PANELS. ALL ROOF PANELS
ARE TO BE SECURED IN THE SAME MANNER.
(2) NOTE: PART NUMBER SHOWN IS FOR TAN / STEEL. REFER TO THE SAMPLE
GUIDE BELOW FOR AVAILABLE COLOR AND/OR ALUMINUM PART NUMBER FORMAT.
0FXXXX0ST01 = TAN / STEEL 0FXXXX0ST13 = BISQUE / STEEL
0FXXXX0AL01 = TAN / ALUMINUM 0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXX0ST08 = T- GRAY / STEEL 0FXXXX0ST14 = GRAY / STEEL
0FXXXX0AL08 = T- GRAY / ALUMINUM 0FXXXXALT14 = GRAY / ALUMINUM
0FXXXX0ST05 = WHITE / STEEL
0FXXXX0AL05 = WHITE / ALUMINUM
(3) PART NUMBER SHOWN IS FOR TAN. SEE GUIDE BELOW FOR AVAILABLE COLOR AND PART NUMBER
FORMAT.
0FXXXX0AL08 = T- GRAY / ALUMINUM 0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXX0AL05 = WHITE / ALUMINUM 0FXXXXALT14 = GRAY / ALUMINUM
