1 0F2687 1 WELDMENT RADIATOR SUPPORT150
2 0F2611 1 RADIATOR 680 X 680 X 70 CPL
3 0F5254 1 V-BELT 31/64" X 62-3/8"
0F5253 1 V-BELT 31/64" X 61-3/8" (5.4L 100KW ONLY)
0F7077 1 V-BELT 1/2" X 63-3/8" (6.8L 100 130KW)
4 046526 12 WASHER LOCK M10
5 051756 8 SCREW HHC M10-1.5 X 20 G8.8
6 0C2454 2 SCREW THF M6-1 X 16 N WA Z/JS
7 052250 2 TAPE FOAM 1 X 1 (26.75” LG)
8 076749 1 TANK COOLANT RECOVERY
9 0F2573 1 PULLEY FAN V-GROOVE 9"
10 0F2610 1 FAN 26" LH ROTATION
11 0F2572 1 ARM TENSIONER
12 0F5689 1 SCREW SHC SHLDR LKG M8 X 16 LG
13 0F2862 1 SPRING TENSION CPL
14 0F2560 1 PULLEY V-BELT 4" FLANGED
15 022131 14 WASHER FLAT 3/8-M10 ZINC
16 039414 1 SCREW HHC M8-1.25 X 35 G8.8
17 052625 3 SCREW SHC M10-1.5 X 35 G12.9
18 0F2561 1 HUB FLEX PLATE
19 0C8165 5 NUT HEX LOCK 5/16-24 NY INS
20 0D6795 1 SCREW HHC M12-1.5 X 60 G8.8
21 0C7043 12 DISK FLEX
22 0E8909 1 COUPLING HUB FLEX (MACH)
23 048031C 1 CLAMP HOSE BAND 1/4
24 0C8146 4 SCREW HHC 5/16-24 X 1.124
25 082774 2 KEY WOODRUFF 4 X 19D
26 0F2686 1 HOSE RADIATOR UPPER CPL
27 0F5463 1 HOSE LOWER RAD CPL C5 6.8L
28 0F8695 1 ASSY BRG/SHAFT CPL FANDRIVE
29 0F4028 1 PULLEY 6.5" DIA MACHINED (6.8L 100KW)
0F4030 1 PULLEY 6" DIA MACHINED (6.8L 130KW)
0F4032 1 PULLEY 5.5" DIA MACHINED (5.4L 80KW & 6.8L 150KW)
0F4496 1 PULLEY 4.5" DIA MACHINED (5.4L 100KW)
30 042911 1 SCREW HHC M10-1.5 X 30 G8.8
31 0F2872 1 SCREW HHC 1/2-13 X 2" G8
32 022304 2 WASHER FLAT 1/2 ZINC
33 022195 1 WASHER LOCK 1/2
34 022196 1 NUT HEX 1/2-13 STEEL
35 049813 8 NUT HEX M6 X 1.0 G8 YEL CHR
36 049820 1 NUT HEX LOCK M8-1.25 NY INS
39 022145 1 WASHER FLAT 5/16-M8 ZINC
40 022129 1 WASHER LOCK M8-5/16
42 035685 4 CLAMP HOSE #28 1.32-2.25
43 045764 1 SCREW HHTT M4-0.7 X 8 BP
44 065852 1 SPRING CLIP HOLDER .37-.62
45 0C7649 1 CLAMP HOSE .38-.87
46 055596 1 BARBED STR 3/8 NPT X 3/8
47 069860E 1 HOSE DRAIN ASSY 28"
48 * 069811 REF CAP HEX 1/4 NPT BRASS
49 080713 1 BRACKET COOLANT TANK
50 022473 16 WASHER FLAT 1/4-M6 ZINC
51 022097 16 WASHER LOCK M6-1/4
52 042568 8 SCREW HHC M6-1.0 X 20 G8.8
53 0F5050 1 SHIELD RADIATOR C5
54 039253 1 SCREW HHC M8-1.25 X 20 G8.8
55 051769 1 WASHER LOCK M12
56 0C8145 8 WASHER FLEX (THIN)
57 0E2507 1 PROBE, COOLANT LEVEL 3/8 NPTF
58 090283 1 CAP RADIATOR 13 PSI
59 0C8566 8 SCREW HHFC M6-1.0 X 20 G8.8
60 0F2776A 1 BRACKET, SIGNAL CONDITIONER
61 052644 1 SPACER .5 X 1.5 X .25 STL/ZINC
* ITEM 48 IS INCLUDED WITH 47.
