Generac Power Systems QT 5.4L User Manual

COMPONENTS INCLUDED IN 0F1826E
1 0F1823 1 ENCL H CONTROL PANEL
2 0F1824 1 COVER CONTROL PANEL
3 0F2606 1 HINGE CONTINUOUS H-PNL
4 036261 6 RIVET POP .125 X .275 SS
5 0F5763 1 ASSY PROGRAMMED PM H-100
6 0F1732 1 DECAL FUSES LOCATED INSIDE
7 0E9764 1 RAIL SNAPTRACK PCB HOLDER BULK (12” LG)
8 0F1725C 1 ASSY PCB 2AMP 12V UL BATT CHGR
9 0F1958 1 PLATE HARNESS CLAMP
10 0F2256 1 ASSY PCB PWR AVR W/AMP HEADER
11 0E3161 1 ASSY PCB BOSCH GOV DRIVER
12 029673 1 DIO BRIDGE 25A 600V
13 049226 8 WASHER LOCK M5
14 079224 4 SCREW PPHM M5-0.8 X 30 SS
15 051713 8 WASHER FLAT M5
16 0F5886 3 SCREW HHPM M5-0.8 X 12
17 051716 5 NUT HEX M5-0.8 G8 CLEAR ZINC
18 0C3990 3 SCREW PHTT M4-0.7 X 10 ZYC
19 043280 3 WASHER FLAT M4
20 055014 10 SCREW PPHM M4-0.7 X 8 BLK OX
21 043184 10 WASHER LOCK M4
22 0F2557 1 DECAL WARNING BATT CHRG 12/24V
23 0F5884 1 SCREW PHTT M3.5-0.6 X 10
24 0C2265 4 SCREW PHTT M4-0.7 X 12 ZYC
25 0F4333 1 CONN DUST CAP W/CHAIN DB9
26 0F5883 1 WASHER FLAT M3.5
27 0F6305 2 SEAL COVER 3.18 X 12.7 X 382
28 0F6305A 1 SEAL COVER 3.18 X 12.7 X 283
29 0F6277 1 ASSY HARNESS H-PNL SW (NOT SHOWN)
COMPONENTS INCLUDED IN WIRE HARNESS
A 0F1263 1 ADPTR RH SIDE WICKMAN 178.6191
B 0F1262 4 HOLDER FUSE WICKMANN 178.6150
C 0F1264 1 ADPTR LH SIDE WICKMAN 178.6192
D 0E9049B 1 ASSY PCB G-PANEL RELAY 12VDC
E 055911 1 BLOCK TERM 20A 12 X 6 X 1100V
COMPONENTS NOT INCLUDED IN 0F1826E OR WIRE HARNESS
50 056739 1 RELAY SOLENOID 12VDC PNL MNT
51 - 1 DPE BREAKER SEE DRAWING 0F9280
52 - 1 BOOST RESISTOR SEE DRAWING 0F9280
53 0F2627A 1 COVER CONTROL PANEL SIDE
54 022287 2 SCREW HHC 1/4-20 X 3/4 G5
55 022473 4 WASHER FLAT 1/4-M6 ZINC
56 022097 2 WASHER LOCK M6-1/4
57 043182 3 WASHER LOCK M3
58 051714 3 NUT HEX M3-0.5 G8 YEL CHR
59 052777 3 WASHER FLAT M3
60 0C2323 2 SCREW PHTT #6-32 X 5/8 ZYC
61 0F5459 1 DECAL CPL CONTROL PANEL FUSES
62 0F5461 1 DECAL 5.4/6.8L TB3
63 022127 2 NUT HEX 1/4-20 STEEL
64 0F5460 1 DECAL CPL 5.4/6.8L RELAY BOARD
65 0E7403C 1 FUSE ATO TYPE 15 AMP (BLUE)
66 0E7403B 2 FUSE ATO TYPE 10 AMP (RED)
67 0F6145 A/R SEAL WEATHER .45" DIA
68 091526 4 SCREW PPHM M5-0.8 X 12 ZNC
69 0C2699 2 SCREW PHTT #6-32 X 3/8 ZYC
70 051713 4 WASHER FLAT M5
71 049226 4 WASHER LOCK M5
