EXPLODED VIEW: EV LOOSE EXHAUST 4.5L G17
DRAWING #: 0J5282A GROUP F
APPLICABLE TO: 0062900
REVISION: -A - Page 2 of 2
DATE: 1/26/12
ITEM PART# QTY. DESCRIPTION
0J5282A61R – EXHAUST PARTS
1 0E7611 1 MUFFLER OPENSET 60KW VZW
2 059936 3 ELBOW 90D 3NPT
3 0E4264 1 BOLT U 3/8-16 X 3.50" W/SADDLE
4 0J5234 1 EXHAUST ADAPTER 3"OD TO 3.5"ID
5 059940 1 RAIN CAP 3.50 / 3.69
6 026073 1 PLUG STD PIPE 1/8 STEEL SQ HD
7 0E3603 1 BLANKET MUFFLER WRAP 3.9L L0SE (NOT SHOWN)
8 0F2773G 1 EXHAUST BLANKET 1500MM LONG (NOT SHOWN)
0J5281033R – FLEX PARTS
9 055978 3 BOLT U 3/8-16 X 3.00
10 0A5215C 1 FLEX PIPE 3"
11 0J5096 1 PIPE EXHAUST ELBOW D4.5L G17
12 0H5480 1 ASSY 4.5L OPEN EXHAUST PIPE
13 096694 1 V-BAND CLAMP EXH ELB
NOTE:
1. ALL PARTS SHIPPED LOOSE.
