Deration – Operational characteristics consider maximum ambient conditions. Derate factors may apply under atypical site conditions. Please consult a Generac Power Systems Industrial
Dealer for additional details. All performance ratings in accordance with ISO3046, BS5514, ISO8528 and DIN6271 standards.
POWER RATINGS (kW)
STARTING CAPABILITIES (sKVA)
FUEL
COOLING
COMBUSTION AIR REQUIREMENTS
ENGINE
EXHAUST
STANDBY
Three-Phase 120/208VAC @0.8pf 600 kW Amps: 2081
Three-Phase 120/240VAC @0.8pf 600 kW Amps: 1804
Three-Phase 277/480VAC @0.8pf 600 kW Amps: 903
Three-Phase 346/600VAC @0.8pf 600 kW Amps: 723
sKVA vs. Voltage Dip
480VAC 208/240VAC
Alternator kW 10% 15% 20% 25% 30% 35% Alternator kW 10% 15% 20% 25% 30% 35%
Standard 600 743 1114 1486 1857 2229 2600 Standard 600 543 814 1086 1357 1629 1900
Upsize 1 832 757 1136 1514 1893 2271 2650 Upsize 1 723 571 857 1143 1429 1714 2000
Upsize 2 - - - - - - - Upsize 2 - - - - - - -
Fuel Consumption Rates*
STANDBY
Fuel Pump Lift - m (ft) Percent Load gph lph
3.7 (12) 25% 18.4 69.7
50% 28.2 88.7
75% 35.6 134.8
100% 41.4 156.7
* Refer to "Emissions Data Sheet" for maximum fuel flow for EPA and SCAQMD permitting purposes.
STANDBY
Coolant Flow per Minute gpm (lpm) 114.1 (432)
Heat Rejection to Coolant BTU/hr 1,589,760
Inlet Air cfm (m3/min) 30,088 (852)
Max. Operating Radiator Air Temp Fº (Cº) 122 (50)
Max. Operating Ambient Temperature Fº (Cº) 104 (40)
Coolant System Capacity gal (L) 13 (49)
Maximum Radiator Backpressure in H
2
O 0.5
STANDBY
Flow at Rated Power cfm (m3/min) 1836 (52)
STANDBY
Rated Engine Speed rpm 1800
Horsepower at Rated kW** hp 909
Piston Speed ft/min 2161.4
BMEP psi 361
** Refer to “Emissions Data Sheet” for maximum bHP for EPA and SCAQMD
permitting purposes.
STANDBY
Exhaust Flow (Rated Output) cfm (m
3
/min) 4980 (141)
Max. Backpressure (Post Silencer) inHg (Kpa) 2.03 (6.9)
Exhaust Temp (Rated Output) ºF (ºC) 1029 (554)
Exhaust Outlet Size (Open Set) 8"
3 of 4
SD600 operating data (60Hz)
600 kW Diesel
