EXPLODED VIEW: EV,CB ASSEMBLY 225AF
DRAWING #: 0J8468 GROUP A
ITEM PART# QTY. DESCRIPTION
REVISION: -A- Page 2 of 2
DATE: 2/3/12
1 REF 1 MAIN CIRCUIT BREAKER
(1)2 045771 4/6 NUT HEX M8-1.25 G8 CLEAR ZINC
(1)3 049897 4/6 SCREW SHC M8-1.25 X 20 G8
(1)4 022129 8/12 WASHER LOCK M8-5/16
(1)5 022145 8/12 WASHER FLAT 5/16-M8 ZINC
(1)6 058306 4/6 SCREW SHC M8-1.25 X 25 C12.9
(1)7 0F8451 4/6 LUG SLDLSS 300 MCM-6 AL/CU
(1)8 0F8843 4/6 BUS BAR 200A LUG ADAPTOR
(1) QTY. REQUIRED FOR 1Ø BREAKERS / QTY. REQUIRED FOR 3Ø BREAKERS.
