EXPLODED VIEW: EV 6.8L G3 CCI MOUNTING BASE
DRAWING #: 0J2569 GROUP C
APPLICABLE TO:
ITEM PART# QTY. DESCRIPTION
REVISION: J-3445-E Page 2 of 4
DATE: 12/5/12
(2)1 0J03380ST0R 1 MTG BASE G6.8L 390 DD CCI
0J03390ST0R 1 MTG BASE G6.8L 390 DD DUAL CCI
0J03400ST0R 1 MTG BASE G6.8L 390 GB CCI
0J03410ST0R 1 MTG BASE G6.8L 390 GB DUAL CCI
0J03420ST0R 1 MTG BASE G6.8L 520 GB CCI
0J0342AST0R 1 MTG BASE G6.8 520 GB MPS
0J03430ST0R 1 MTG BASE G6.8L 520 GB DUAL CCI
0J0343AST0R 1 MTG BASE G6.8L 520 GB DUAL MPS
2 024310 1 PLUG STD PIPE 1/2 STEEL SQ HD
3 052252 4 DAMPENER VIBRATION
2 DAMPENER VIBRATION (520 ALT G/B)
4 052257 4 SPACER .49 X .62 X 1.87 PWDR/ZINC
2 SPACER .49 X .62 X 1.87 PWDR/ZINC (520 ALT G/B)
5 052259 4 WASHER FLAT M12
2 WASHER FLAT M12 (520 ALT G/B)
6 055597 4 SCREW HHC M12-1.75 X 85 G8.8
2 SCREW HHC M12-1.75 X 85 G8.8 (520 ALT G/B)
7 052251A 4 DAMPENER VIBRATION 50 WHITE
2 DAMPENER VIBRATION 50 WHITE (520 ALTG/B ONLY)
8 052860 4 NUT LOCKING M12-1.75
2 NUT LOCKING M12-1.75 (520 ALT G/B ONLY)
9 0D2007 1 ENGINE MOUNT 6.8L RH SIDE
10 0D2006 1 ENGINE MOUNT 6.8L LH SIDE
11 REF REF KIT VARMIT GUARD
REF REF KIT VARMIT GUARD
REF REF KIT VARMIT GUARD
12 051756 1 SCREW HHC M10-1.5 X 20 C8.8
15 025507 1 WASHER LOCK EXT 7/16 STL
16 038805J 1 CABLE BATT BLK #1 X 30.00 NEG
(1)17 0H8626 2 SCREW HHC 5/8-11 X 5 G8 (520 ALT G/B)
(1)18 089743 2 NUT HEX LOCK 5/8-11 NY INS (520 ALT G/B)
(1)19 022247 4 WASHER FLAT 5/8 ZINC (520 ALT G/B)
(1)20 059676 2 MOUNT LOWER VIBRATION (520 ALT G/B)
(1)21 059675 2 MOUNT UPPER VIBRATION (520 ALT G/B)
22 045771 1 NUT HEX M8-1.25 G8 YEL CHR
23 0C3168 1 5/16 SPECIAL L/WASH
24 022129 1 WASHER LOCK M8-5/16
25 052243 4 SCREW HHC M10-1.5 X 60 G8.8
26 052648 4 SCREW SHC M10-1.5 X 20 C12.9
27 022131 9 WASHER FLAT 3/8-M10 ZINC
28 046526 9 WASHER LOCK M10
29 030985 1 NIPPLE CLOSE 1/2 X 1.125
30 078944 1 VALVE BALL
31 044118 1 BARBED STR 1/2 NPT X 5/8
32 0G0015 2 CLAMP HOSE 7/8" OD DOUBLE WIRE
33 065386 1 HOSE 5/8 ID SAE100R6 (11”LG)
34 044117 1 BARBED STR 3/8 NPT X 5/8
35 057765 1 ADP OIL DRN M14-1.50
36 057772 1 WASHER NYLON .565
37 0536210360 1 WIRE ASSEM #4GA GRD
38 043107 1 SCREW HHC M8-1.25 X 25 G8.8
39 022145 1 WASHER FLAT 5/16 ZINC
40 050331 1 BATT POST COVER BLK -
41 050331A 1 BATT POST COVER RED +
42 03880400AA 1 CABLE BATT RED #1 X 44.00 (G/B)
038804J 1 CABLE BATT RED #1 X 40.50
