EXPLODED VIEW: EV ENGINE COMM PARTS 6.8L L/H
DRAWING #: 0J2563 GROUP D
APPLICABLE TO:
REVISION: J-2555-E Page 3 of 4
DATE: 8/22/12
ITEM PART# QTY. DESCRIPTION
51 023897 2 WASHER FLAT #10 ZINC
52 022152 2 WASHER LOCK #10
53 022158 2 NUT HEX #10-32 STEEL
54 0G9378 1 DECAL SORE EPA CERTIFICATION
0H0777 1 DECAL LSI EPA CERTIFICATION
(1) NOTE: I/N 18 IS FOR HOLDING SENSOR TO I/N 35.
(2) NOTE: COMES WITH ENGINE
(3) NOTE: NOT SHOWN
(4) 150KW UNITS ONLY
