EXPLODED VIEW: EV FUELSYS G6.8L G3 NG & LPV
DRAWING #: 0H6703 GROUP E
ITEM PART# QTY. DESCRIPTION
REVISION: J-4132-E Page 2 of 2
DATE: 2/6/13
1 049721 4 SCREW HHC M6-1.0 X 35 C8.8 BLK
2 0H5093 1 ASSY RGLTR INLET NPT FITTINGS
A 065908 1 SUPPORT NAT GAS SOLENOID
B 039130 1 NIPPLE CLOSE 1.25NPT X 1.625
C 030131 2 ELBOW 90D 1-1/4 NPT
D 088963 1 NIPPLE PIPE 1.25NPTX5.5 BL IRN
E 0A8064 1 BSHG RDCR HEX 1-1/4-3/4
F 026915 1 NIPPLE CLOSE 3/4 X 1.375
2 0J3809 1 ASSY RGLTR INLET NPT FITTINGS
A 065908 1 SUPPORT NAT GAS SOLENOID
B 0A8064 1 BSHG RDCR HEX 1-1/4-3/4
C 026490 1 NIPPLE PIPE 3/4NPT X 2
D 026812 2 ELBOW 90D 3/4NPT
E 035589 1 NIPPLE PIPE 3/4 NPT X 3-1/2
F 0J3858C 1 BALL VALVE, 3/4" NPT
G 026915 2 NIPPLE CLOSE 3/4 X 1.375
3 0G8598A 1 REGULATOR ASSY 6.8L 60KW LPV
0G8598B 1 REGULATOR ASSY 6.8L 70KW NG
0G8598C 1 REGULATOR ASSY 6.8L 50/70 LPV
0G8598D 1 REGULATOR ASSY 6.8L 50KW NG
4 052617 2 SCREW HHC M12-1.75 X 20 C8.8
5 022304 2 WASHER FLAT 1/2 ZINC
6 051769 2 WASHER LOCK M12
7 045773 2 NUT HEX M12-1.75 G8 YEL CHR
8 042568 2 SCREW HHC M6-1.0 X 20 C8.8
9 0F6155 1 HARNESS,FUEL JUMPER SINGLE REG
(1)10 0G46350ST0R 1 BRACKET, HOSE RISER
11 022097 10 WASHER LOCK M6-1/4
12 0D2698 1 GASKET ADAPTER THROT BODY
13 057823 4 CLAMP HOSE #10 .56-1.06
14 059057 2 HOSE 3/4 ID SAE-30R2 (40.5” LG)
15 049811 2 WASHER FLAT M6
18 0J7476 1 ADAPTOR THROTTLE BODY
19 0E4390 1 GASKET, GOVERNOR ACTUATOR
20 0E4392 1 ACTUATOR BOSCH 60, GOVERNOR
21 0F0960 1 REDUCER 3.0" TO 2.75" TURBO
22 0F3885 1 MIXER, 40/60MM ACTUATOR ASSY
23 0G3167 2 O-RING 2-3/4 X 3/32 X 2-15/16
24 0F3691B 1 VENTURI, THROTTLE 36MM
25 026073A 1 PLUG STD PIPE 1/4 STEEL SQ HD
26 0D2157 4 SCREW SHC M6-1.0 X 50 C8.8
27 039294 2 CLAMP HOSE #44 2.31-3.25
28 050279A 1 DECAL FUEL INLET NG 1 1/4" NPT
29 0D1509 1 DECAL INLET PRESSURE
NOTES (UNLESS OTHERWISE SPECIFIED):
(1) SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR)
• MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM.
• CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR
CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).
