EXPLODED VIEW: EV 390 ALT SHROUD KIT CCI
DRAWING #: 0J7592 GROUP H
ITEM PART# QTY. DESCRIPTION
REVISION: -A- Page 2 of 2
DATE: 11/21/11
(1)1 0J7590AST0R 2 SHROUD 390 ALT X 76MM
0J75900ST0R 2 SHROUD 390 ALT X 50MM
0J75910ST0R 2 SHROUD 390 ALT X 150MM
(2)2 0C2454 8/10 SCREW HWHT M6-1 X 16 N WA Z/JS
3 0E1534A 4 PLUG PLASTIC 1.50"
(1)NOTE:
0J7590AST0R INCLUDED IN KIT #0J7593A
0J75900ST0R INCLUDED IN KIT #0J7593
0J75910ST0R INCLUDED IN KIT #0J7593B
(2) QTY DETERMINED BY SHROUD MOUNTING REQUIREMENTS.
