General 15-250 M1

28
PARTS LIST - 15-250 M1
PART N0. REF N0. DESCRIPTION SPECIFICATION QTY
15250-01 20900001 DRUM 2
15250-02 20703010 TWO-STEP CLAMP 2
15250-03 20703010B TWO-STEP CLAMP PLATE 2
15250-04 20703010A SPRING 2
15250-05 20703014A SPRING 2
15250-06 20703014 FIXED CLAMP BRACKET 2
15250-07 20703014B FIXED CLAMP PLATE 2
15250-08 20703014C SPRING 2
15250-09 S0040300 PHILLIPS HEAD SCREW 2
15250-10 S0110300 NUT 3/16"-24UNC 7
15250-11 20900086 RIGHT CLAMP 3
15250-12 20900087 LEFT CLAMP 3
15250-13 20900069 MICRO-ADJUSTMENT SPRING 6
15250-14 S0030580M PHILLIPS HEAD SCREW 6
15250-15 S0120500M NYLON NUT M5X0.8 6
15250-16 20900002 CLAMP BLOCK 2
15250-17 20900003 RIGHT BEARING HOUSING 1
15250-18 20900004 LEFT BEARING HOUSING 1
15250-19 20900005 RIGHT MICRO-ADJUST.BEARING CAP 1
15250-20 20900006 LEFT MICRO-ADJUST.BEARING CAP 1
15250-21 S0020530A MICRO-ADJUSTMENT SCREW 2
15250-22 S05ETW06 CIRCLIP E6 8
15250-23 20703002 BEARING CAP 6
15250-24 C1206205 BEARING 6205 4
15250-25 S0060510 CAP SCREW 8
15250-26 S0210500C FLAT WASHER 38
15250-27 S0230506 LOCK WASHER 5/16" 62
15250-28 S0120500 NUT 5/16"-18UNC 30
15250-29 20900008 DRIVE ROLLER 2
15250-30 S0210532 FLAT WASHER 3/8"X23 2
15250-31 S0020512L LEFT THREADED SCREW 5/16"-18UNCX1"L 2
15250-32 20900009 CORNER BRACKET 4
15250-33 20900010 FRONT UPPER PANEL 1
15250-34 20900011 DUST HOOD SUPPORT PANEL 1
15250-35 20702019 HINGE 2
15250-36 20900012 DUST HOOD/DRUMS COVER 1
15250-37 20703016 DUST HOOD/DRUMS COVER HANDLE 1
15250-38 S0010502 CAP SCREW 5/16"-18UNCX3/4"L 18
15250-39 20900070 UPPER CLASP 1
15250-40 20900071 LOWER CLASP 1
15250-41 20900068 HINGE PAD SS41 2
15250-42 S0030405 PHILLIPS HEAD SCREW 1/4"-20UNC 24
15250-43 S0210401 FLAT WASHER 1/4"X13X1 41
15250-44 S0110400 NUT 12
15250-45 20900013 PULLEY GUARD 1
15250-47 S0230400 LOCK WASHER 1/4" 46
15250-48 20900014 UPPER BRACKET 2
15250-49 20900015 COLUMN SUPPORT BRACKET 2
15250-50 20900016 LOWER BRACKET 2
15250-51 20900017 WORM GEAR 2
15250-52 20900018 WORM 2
