General 15-250 M1

29
PARTS LIST - 15-250 M1
PART N0. REF N0. DESCRIPTION SPECIFICATION QTY
15250-53 20900019 BUSHING 2
15250-54 S0520080 CIRCLIP S80 4
15250-55 S0050500 SET SCREW 16
15250-56 S0050406 SET SCREW 5
15250-57 20900020 SCREW HOLDER 2
15250-58A C5151102 BEARING 51102 2
15250-58 20900021 BRONZE COLLAR 2
15250-59 20900022 BEVEL GEAR 4
15250-60 S0010616M HEX HEAD BOLT M6 X 1.0 X 16 4
15250-61 S0010303 HEX HEAD BOLT 3/16"-24UNCX3/8" L 8
15250-62 20900023 GEAR SHAFT BUSHING 2
15250-63 20900024 POSITIONING COLLAR 2
15250-64 20900025 TRANSMISSION SHAFT 1
15250-65 20900067 MOUNTING BRACKET 4
15250-66 20900026 POST COVER 2
15250-68 S0040307 PHILLIPS HEAD SCREW 5/16"-18UNCX1"L 8
15250-69 20900028 BRONZE COLLAR COVER 2
15250-70 S0520015 CIRCLIP S15 2
15250-71 S0310420 PIN 4X20 1
15250-72 20900029 CRANK HANDLE 1
15250-73 10105056A HANDLE KNOB 1
15250-74 20900030 SWITCH MOUNTING PLATE 1
15250-75 W2092301D MAGNETIC SWITCH 1
15250-76 S0030318 SCREW 3/16"-24UNCX3/4"L 4
15250-77 S0040308 FLAT HEAD SCREW 3
15250-78 10401008 CORD BUSHING 1
15250-79 20900066 SWITCH REAR GUARD 1
15250-80 20900031 MOTOR BASE 1
15250-81 S0020501 HEX HEAD BOLT 28
15250-82 20900032 MOTOR ADJUSTMENT PLATE 1
15250-83 M0000000 MOTOR 1
15250-84 20900033 DRIVE PULLEY 1
15250-85 S0430640 KEY 6X40 3
15250-86 20900034 BASE SHAFT 1
15250-87 20900035 POSITIONING SHAFT 2
15250-88 20900036 SCREW 2
15250-89 20900037 FRONT COVER 1
15250-90 20900038 REAR COVER 1
15250-91 20900039 FRONT PANEL 1
15250-92 20900040 REAR PANEL 1
15250-93 S0010500 CAP SCREW 5/16"-18UNCX1/2" 20
15250-94 20900041 SHIELD PLATE 2
15250-95 S0020408 CAP SCREW 1/4"X1/2" 8
15250-96 20900042 RIGHT COVER 1
15250-97 20900043 LEFT COVER 1
15250-98 20900044 GRADUATED SCALE 1
15250-99 20900045 INDICATOR 4
15250-100 20900046 BELT PLATEN 1
15250-101 20900047 MICRO-ADJUSTMENT BLOCK 2
15250-102 20900048 MICRO-ADJUST. MOUNTING BRACKET 2
15250-103 20900049 BEARING CAP 4
