30
PARTS LIST - 15-250 M1
PART N0. REF N0. DESCRIPTION SPECIFICATION QTY
15250-104 20900050 FRONT CONVEYOR ROLLER 1
15250-105 20900051 POSITIONING PLATE 1
15250-106 20900052 CONVEYOR DRIVE ROLLER 1
15250-107 C1106202 BEARING 6202 4
15250-108 S0120200 NYLON NUT 1/4"-20UNC 10
15250-109 20900053 PAD 2
15250-110 20900054 SHAFT JOINT 2
15250-111 S0050404C SCREW 1/4"-20UNCX1/4"L 2
15250-112 20900055 ELECTRIC CONTROL BOX 1
15250-113 20701011 ELECTRICAL INSULATION BOARD 1
15250-114 S0040510M PHILLIPS HEAD SCREW 2
15250-115 W0000001 SAFETY SWITCH 1
15250-116 S1017W-2 PLASTIC CLAMP 1
15250-117 S1006P-4 PLASTIC CLAMP 6P-4 1
15250-118B M2090002 SPEED REDUCTION MOTOR 1
15250-119B 20900073 PC BOARD 1
15250-120 40501019 REGULATOR KNOB 1
15250-121 40501018 PC BOARD MOUNTING PLATE 1
15250-122 20900056 BOTTOM COVER, ELECTRIC CONTROL BOX 1
15250-123 S0030304 PHILLIPS HEAD SCREW 3/16"-24UNCX1/4"L 18
15250-124 S0010615M CAP SCREW 1/4"-20UNCX3/4"L 18
15250-128 10401029 FOOT PAD 4
15250-129 S0090512 SCREW 5/16"-18UNCX5/8"L 4
15250-130 S0010503A CAP SCREW 5/16"-18UNCX4"L 2
15250-131 20900060 PRESSURE ROLLER FRONT 2
15250-131A 20900060A PRESSURE ROLLER REAR 1
15250-132 20701006 BEARING 6
15250-133 S0520028 CIRCLIP S28 2
15250-134 S0040410 PHILLIPS HEAD SCREW 1/4"-20UNCX5/8"L 4
15250-135 V0017500 V-BELT 2
15250-136 20900061 CONVEYOR BELT 1
15250-137 L000000M POWER CORD 1
15250-138 L0000000 CORD 1
15250-139 L2090001 SWITCH WIRE 2
15250-140 L2090002A WIRE WITH TERMINALS 2
15250-141 20900062 SANDING BELT (SEE 15-253) P80 1
15250-142 20900063 SANDING BELT (SEE 15-255) P120 1
15250-143 J2090001 WARNING LABEL 1
15250-144 J2090002 WARNING LABEL 1
15250-145 10101002 COVER CUSHIONS 4
15250-147 20900064 COVER PANEL 1
15250-148 S0911214 COMBINATION WRENCH(NOT SHOWN) 12/14MM 1
15250-149 S1206150 T HANDLE ALLEN WRENCH(NOT SHOWN) 6MM 1
15250-149A S1202100 T HANDLE ALLEN WRENCH
(NOT SHOWN) 2MM 1
15250-149B S0910103 ALLEN KEY
(NOT SHOWN) 5 MM 1
15250-161 20900081 SPACER 1
15250-162 20900082 SIDE PANEL 2
15250-163 20900083 FRONT PANEL 1
15250-164 20900084 REAR PANEL 1
15250-165 20900100 SCALE POINTER 2
15250-166 20900101 ADJUSTING COLLAR 2
