10
▪ Press and hold the line / pulse mode button
on the top of the instrument for 5 seconds to
enter into pulse mode.
▪ Switch the detector on by pressing the
power button. The speaker will beep
indicating the instrument is operating.
▪ Move the detector into the path of the laser
beam.
▪ Hold the detector upright for horizontal
beams. Rotate the detector 90° for vertical
beams.
▪ The LED direction indicators will indicate
the position of the laser beam. The centre
LED will indicate alignment with the beam.
USING YOUR DETECTOR
Detector position for horizontal beams
Detector position for vertical beams
The detector is an optional accessory
which can be purchased from your retailer.
i
