STANDARD ACCESSORIES
The following installation parts are furnished. Use them as required.
INDOOR UNIT ACCESSORIES
Name and Shape
Cover plate (left)
Cover plate (right)
Tapping screw ( 4x10)
Installation template
Bracket (left)
Bracket (right)
Anchor bolt (M12)
Spring washer
Special nut
Wall bracket
Tapping screw ( 4x20)
Coupler heat insulator
(large)
Coupler heat insulator
(small)
Nylon fastener
Q'ty
1
1
2
1
1
1
4
4
4
2
6
1
1
1
Application
For positioning the indoor
unit
For under ceiling type
For suspending the indoor
unit from ceiling
For suspending the indoor
unit on the wall.
For fixing the wall bracket.
For indoor side pipe joint
(Large pipe)
For indoor side pipe joint
(Small pipe)
For fixing the drain hose
Name and Shape
Drain hose
Insulation (drain hose)
VT wire
Remote control unit
Battery (penlight)
Remote control unit holder
Tapping screw ( 3x12)
Q'ty
1
1
1
1
2
1
2
Application
Adhesive type 70 x 230
For fixing the drain hose
L 280 mm
Use for air conditioner
operation
For remote control unit
Use as remote control unit
holder
For remote control unit
holder installation
OUTDOOR UNIT ACCESSORIES
Application
For outdoor unit drain piping
work
[Heat & Cool model
(Reverse cycle) only]
Q'ty
1
2
Name and Shape
Drain pipe
Drain cap
OPTIONAL PARTS FOR INDOOR UNIT
Name and Shape Part No. Application
Joint pipe-A
9302812021
For indoor side pipe joint
2004.01.09 35
