30
25
26
27
27
29
29
28
INDOOR UNIT
22
23
24
21
2007.10.29 19
25
23 Casing B 9374234011
Bracket Motor Assy A 9374230020
24 Sirocco Fan Assy 9356531039
29 Rubber 9385102002
21 Base Sub Assy 9374504015
22 Separate Wall Assy 9374228010
30 Bracket (Eva.) R 9374207015
28 Motor, Induction 9602433018
26 Bracket Motor Assy B 9358591000
27 Bracket Motor C 9358594001
Ref. Description
Part number
-- Bracket (Eva.) L 9374208012
