General AOHR12LGC

PARTS
1
1
2
9
12
3
15
14
10
13
11
5
6
7
8
4
OUTDOOR UNIT
AOHR09LGC
AOHR12LGC
15
4 Top Panel Assy 9316973022
1 Front Panel Assy 9316972018
5 Protective Net 9331262019
3
6
Cabinet Left Assy 9313991043
2 Emblem 9317379007
Switch Cover 9310979013
8 Valve Bracket 9316523012
7 Cabinet Right Assy 9331336055
9 Valve Bracket Cover 9331683005
11 Motor Bracket 9316538009
12 REM Plate Assy (12) 9316967021
10 Propeller Fan 9309909014
12 REM Plate Assy (09) 9316967038
14 Reactor Assy 9900357023
15 Separator Assy 9317392006
13 Fan Motor (09) 9602706006
13 Fan Motor (12) 9602751006
Ref. Description Part number
2008.01.31
