General AOHR24LCC

OUTDOOR UNIT
AOHR24LCC
Ref
No.
Parts No.
Description
11 9900056018Pulse Motor Valve
10 99001630134-Way Valve
44 9703457012ACTPM
14 313728262708Thermistor Spring A
20 9315296023Base Assy
33 9703516108Outdoor Temp. Thermistor
38
9704219091
Discharge Thermistor
37 9704220059Heat Exchanger Thermistor
40 9707121056Inverter PCB Assy
41 9707128055Capacitor PCB Assy
42 9707129052Power PCB Assy
43 9707125054TR PCB Assy
8 9309237032Switch Cover Assy
32 9900057039Expansion Valve Coil
39
9970055010
Solenoid
7 9308880017Grip
16 9309909014Propeller Fan
36 9315211019Emblem Rear
18 9313432027Motor Bracket Assy
6 9308885012Fan Ring
22 93130620192-Way Valve Assy
21 93154140143-Way Valve Assy
54 9315312013Discharge Pipe Assy
50 9315310019Pulse Motor Valve Assy
51
9315308016
JNT PIPE(3WV)AS
52 9315304018PIPE(COND OLT)AS
53 9315305015PIPE(COND ILT)AS
25 9703874031Terminal, 5 Pin
45
0500158072
Fuse Holder
46 0600086039Fuse
4 9308884015Blow Grill
24 9307271014Cord Clamp
34 9602110018DC Brushless Motor
1 9309230064Top Panel Assy
5 9309236028Cabinet Right Assy
3 9314809019Cabinet Sub Assy
12 9315303011Condenser Assy B
35 9315297013
13 9315302014Condenser Assy
Compressor Assy
212006.06.21
Ord.
Q'ty
55 Chock Coil 9900366018
