When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
2 Fan Guard 9371187013
4 Emblem 9372171011
5 Front Panel Painted 9371924014
7 Connecteor Cover (Cabinet) 9366398004
Inverter Assy (Ref. No.32)
Ref.
No.
Description
Ord.
Q'ty
Part No.
12 Base Assy, Painted
9371920078
13-1 3-Way Valve
9372205044
13-2 2-Way Valve 9372204054
16 Condenser Assy 9372181096
26-1 Compressor Cover A 9373730019
26-2 Compressor Cover B 9373730026
31 PWB Assy 9705285019
29 Separate Wall 9372795019
17 Thermister Holder Pipe 313714262805
45-1 Motor Bracket 9371929019
45-2 Motor Bracket-Top 9371931012
45-3 Motor Bracket-Ctr 9371930015
45-4 Motor Bracket-Bottom 9371932019
46 Compressor Assy 9373262015
39 Propeller Fan Assy
9366378013
41 Motor Induct 9601671046
34 Capacitor, Plastic 9704305077
33 Control Cover 9372792018
--- Capacitor, Elec 9705387010
34 Capacitor, Plastic 9704305077
--- Fuse 0600086039
--- Terminal 8P 9900203047
--- Fuse Holder 0501454012
--- Terminal 2P 9701971015
--- ACTPM 9703457012
31 Controller PCB Assy 9705285019
Ref.
No.
Description
AOH24LMAM2
Ord.
Q'ty
Part No.
AOH24LMAM2
411 Gasket 9373266013
527
Protective Net 9371934013
734
Top Plate 9371925011
735-3
Capillary Assy 9373729211
754
Washer (Rubber) 9358078006
361 Accum Support Assy 9372252017
Ref.
No.
Description
Ord.
Q'ty
Part No.
64 Side Panel L Ptd 9371926018
69-3 Bolt, hex, Socket 301210060360
85 Valve Plate Ptd 9371928036
109 Terminal Cover (Comp) 9373264019
187 Clip (Cable) 9352715006
199 Br Sheet 9363708042
218-3 Relay 9900117016
108 Rubber Seat (Comp) 9358080009
260 Receiver Tank Assy 9373426011
273 Strainer Assy 9366602019
349 Capirarry Assy 9373729211
335 Accumlator Holder Rubber 9354022010
343 Solenoid 9900165079
344 4-Way Valve 9900163013
345 Joint Pipe (3Way) Assy 9373729129
346 Expansion Valve Assy 9373729068
348 Pressur Switch Assy 9373729044
334 Accumlator 9368391003
14 Valve Cover 9372796016
13-3 3-Way Valve 9372205051
15 Condenser Sub Assy 9372313121
55 Special Nut M8 9355091008
