General ASHB09LDC User Manual

PARTS LIST
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "order" column.
INDOOR UNIT
1 Air Filter-L 9312920013
2 Air Filter-R 9312921010
3 Front Panel 9312914029
4 Top Grill 9313948016
5 Intake Grille Assy 9313157081
6 Clamper (Grille) 9306755010
7 Louver-U 9309991033
8 Louver-Z 9309992030
9 Holder (Louver) Assy 9309993013
10 Gear-A 9309994003
11 Casing Assy 9311354079
12 Cover (Casing)-F 9309987005
13 Cover (Casing)-B 9314160011
14 Crossflow Fan Assy 9307836015
15 Clamper (Motor) 9310102008
16 Bearing-C Assy 9306628017
17 Hose (Drain) Assy 9314147012
18 Cap (Drain) Assy 9314493010
19 Wire Clamper 9311946014
20 Box Switch 9312908011
21 Cover (Switch) 9312909018
22 Evaporator Total Assy
9313099015
23 Filter Guide
9313920012
25 H-Ins. (Pipe)-E 9304607007
26 Evaporator Holder-L Assy 9313174019
27 Evaporator Holder-R
9309983014
28 Water Seal 9312912018
29 Bracket (Eva. )
9310464007
30 Power Cord Assy
9900339012
31 Controller PCB Assy 9707116021
---- Transformer, Switch T1 9705054011
---- Varister VA1 0000785020
---- Fuse FSL 250 3.15(EM) 0600376062
---- Fuse Holder FH1-FH2 0500158072
---- Relay DW12D1 K1 9704185013
---- Manual Auto Switch SW1 9703476013
---- Cover (Display) 9312917013
---- Display Cover 9312918010
---- Receiver Window 9312919017
---- Holder (Outdoor Thermistor) 9307178023
32 Indicator PCB Assy 9705375024
33 Air Cleaner Assy 9313148041
36 Motor, Step 9900139025
37 Motor, Brushless DC 9602109012
38 Remote Control Unit Assy 9315027047
39 Air Clean Filter 9313275013
40 Bracket Panel Assy 9310001004
Ref.
No.
Description
Ord.
Q'ty
Part No.
ASHB12LDC
9312920013
9312921010
9312914029
9313948016
9313157081
9306755010
9309991033
9309992030
9309993013
9309994003
9311354079
9309987005
9314160011
9307836015
9310102008
9306628017
9314147012
9314493010
9311946014
9312908011
9312909018
9313099015
9313920012
9304607007
9313174019
9309983014
9312912018
9310464007
9900339036
9707116014
---- Room Temperature Thermistor 9700801108
---- Pipe Temperature Thermistor 9702039042
9700801108
9702039042
9705054011
0000785020
0600376062
0500158072
9704185013
9703476013
9312917013
9312918010
9312919017
9307178023
9705375024
9313148041
9900139025
9602109012
9315027047
9313275013
9310001004
41 Remote Control Unit Holder 93056420459305642045
ASHB09LDC
142006.02.06
