INDOOR UNIT
SLIM DUCT
ARHG07LLTA
ARHG09LLTA
ARHG12LLTA
ARHG12LLTB
(Serial number : T)
Refer to the service
bulletin RAC-0059
3 Pipe Panel Sub Assy
1 Side Panel R Sub Assy
2 Side Panel L Sub Assy
5 Outlet Frame Sub Assy
Parts numberDescriptionRef
Panel (Window) Sub Assy
3
12
11
13
14
16
7
2
9
10
4
1
672013.06.20
12 Cabinet Panel (2 Fan)
9 Fan Guard (2 Fan)
11 Main Panel Sub Assy
13 Drain Cap
14 Drain Pan Sub Assy
9379906005
9379900003
9379907002
9379909006
9379915007
9379596008
9379637008
9379902007
9358746004
9379901000
4
Parts numberDescriptionRef
15
Evaporater Total Assy (07)
16 Pipe Thermistor
9380782087
15
Evaporater Total Assy (09, 12)
9380782049
9900623005
10 Air Filter 9379574006
7 Valve Cover Sub Assy 9379576000
6 Front Panel (2 Fan) 9379593007
8 Cover Pipe Sub Assy 9380033004
-- Hose Sub Assy 9378450103
5
6
8
15
