17
18
16
12
15
19
20
11
21
14
13
2013.06.20 49
15
Air Filter
9318910001
12
Front Panel 9318876000
16 Display Plate Holder L 9318894004
14
Front Panel Cover U
17 9318895001
18 Display Plate R 9318893007
Display Plate Holder R
19 9318900002
20 Grille Stay 9318899016
21 Grille Clamper B 9316951006
Arm Cover
9318883015
13 Intake Grille Assy 9319351094
11 Front Panel Total Assy 9319348117
Ref. Description Part number
INDOOR UNIT
COMPACT WALL MOUNTED
ASHG07LUCA
ASHG09LUCA
ASHG12LUCA
ASHG14LUCA
Front panel
