21 Condenser Total Assy
22 Separater Assy (14)
25 2-way Valve Assy
26 3-way Valve Assy
28 Expansion Valve Assy
23 Reactor Assy (14)
29
Expansion Valve Coil (L=650)
30
Expansion Valve Coil (L=850)
9314107061
9379344012
22 Separater Assy (18) 9317781015
9317171038
9317174053
9379334013
27 Valve Bracket 9379194013
9900611019
23 Reactor Assy (18) 9900641016
24 Compressor Assy (14) 9379315012
24 Compressor Assy (18) 9379679008
9970095016
9970096044
31 Solenoid 9970033032
32 4-way Valve 9970065019
Ref. Description Part number
42
OUTDOOR UNIT
26
25
25
29
30
28
32
31
24
27
22
21
23
26
2012.02.09
